1-3
1.3 DISASSEMBLY/ASSEMBLY OF CABINET PARTS
1.3.1 Disassembly flow chart
This flowchart indicates the disassembly step for the cabi-
net parts and board assembly in order to gain access to
item(s) to be serviced. When reassembling, perform the
step(s) in reverse order. Bend, route and dress the flat ca-
bles as they were originally.
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
1 Cassette cover assembly
2 Upper case
3 Lower case assembly
(Incl. E. VF assembly)
4 E. VF assembly
5 Top operation unit assembly
6 Rear unit
7 Front cover assembly
(Incl. Microphone,
DC light assembly)
8 Microphone
9 DC light assembly
0 Monitor assembly
- Front frame assembly
3a 2 SPEAKER MAIN CN27
3b
20 C-VF BL CN7551 MAIN CN11
5 E. VF (B/W) MAIN CN12
5a 12 TOP OPERATION UNIT MAIN CN18
6a 13 REAR UNIT MAIN CN28
7a 2 MIC MAIN CN8
8a 33 MONITOR ASSEMBLY MAIN CN16
11a 28 MONITOR CN7501 T. HINGE
11b 24 MONITOR CN7502 LCD MODULE
11c 2 MONITOR CN7503 BACK LIGHT
1.3.2 Disassembly method
List of Abbreviations:
2(S1)=2 screws (S1)
4(L1a)=4 Locking Tabs
CN=Connector
1 CASSETTE C1 2(S1)
COVER ASSEMBLY
2
UPPER CASE C2 2(S2), (L2)
3 LOWER CASE C3 9(S3), (L3a), (L3b)
ASSEMBLY (INCL. *CN 3a 3b
E. VF ASSEMBLY) CAP (RCA jack)
4 E. VF ASSEMBLY C4 3(S4)
5 TOP OPERATION C5 2(S5), (L5a), (L5b), (L5c)
UNIT ASSEMBLY *CN 5a
6 REAR UNIT C6 3(S6), (L6a), (L6b)
*CN 6a
7 FRONT COVER C7 2(S7a), (S7b), (L7a), (L7b)
ASSEMBLY (INCL. MIC *CN 7a
DC LIGHT ASSEMBLY)
8 MICROPHONE (S7a)
9 DC LIGHT ASSEMBLY 2(L7c)
0 MONITOR ASSEMBLY C8 2(S8a), (S8b)
*CN 8a
C9 2(S9a), (S9b), (S9c)
C10 2(S10a), 2(S10b), 2(S10c),
(L10a), (L10b), (L10c)
C11 (L11a), (L11b), (L11c)
*CN 11a , 11b , 11c
C12 2(S12a), (S12b), 2(L12a)
- FRONT FRAME C13 2(S13)
ASSEMBLY
STEP
/LOC PART
NO.
REMOVAL
Fig.
No.
Reference Notes:
<NOTE 1>
Destination of connectors
Note:
Two kinds of double-arrows in connection tables
respectively show kinds of connector/wires.
: Flat wire
: Wire
Con- No. of
nector Pins
Connector
*UNLOCK/RELEASE/
UNPLUG/UNCLAMP/
UNSOLDER
To Next Page
