JVC GZ-MG67AA Service Manual

(No.YF147)3-7
PACKING AND ACCESSORY ASSEMBLY <M5>
MAIN BOARD ASSEMBLY <01>
351D LY30727-008A TAPPING SCREW (x7)
352 LY45185-001A OPTICAL LPF SET 010
353 LY45186-001A SHEET SET 010
354 LY35264-001B BKT(OP)ASSY SET 010
354A LY42796-001A BUSH SET 010(x4)
355 LYH30669-001A CCD BASE ASSY
356 QYSPSGU1750ZA TAP SCREW SET 010 M1.7 x 5mm(x2)
357 LY35266-201A SHIELD(CCD)MEGA FOR JPN
358 LY35311-001A-ML HEAT SHEET(CCD) JPN
359 LY30032-007A SPECIAL SCREW SET 010(x2)
360 LY42424-001B SPECIAL SCREW SET 010(x2)
362 LY30035-021A SPACER(A)
363 LY30035-022A SPACER(A)
364 LY30035-023A SPACER(A)
365 LY30035-040A SPACER(A)
 Symbol No. Part No. Part Name Description Local
001 LY34452-001A POLY BAG DOCUMENT
002 LY35273-003A-S CD ROM ASSY
 003 LYT1549-001A INST BOOK(EN) (ENGLISH) A,C,D,E,G,H,J
 003 LYT1549-002A INST BOOK(CS) (SIMPLIFIED CHINESE) C,D,F,G,H
 003 LYT1549-003A INST BOOK(RU) (RUSSIAN) J
 003 LYT1549-004A INST BOOK(AR) (ARABIC) C,G,J
 003 LYT1549-005A INST BOOK(GE) (GERMAN) J
 003 LYT1549-006A INST BOOK(FR) (FRENCH) J
 003 LYT1549-007A INST BOOK(PE) (PERSIAN) J
 003 LYT1629-001A INST BOOK(CS) (SIMPLIFIED CHINESE) B
004 LYT1534-002A INST BOOK(SOFT.EN) (SOFT.ENGLISH) A,E,J
004 LYT1534-003A INST BOOK(SOFT.S-CH) (SOFT.SIMPLIFIED CHINESE) B,F
004 LYT1534-004A INST BOOK(SOFT.ENSCHAR) (SOFT.ENGLISH SIMPLIFIED CHINESE ARABIC) C,G
004 LYT1534-005A INST BOOK(SOFT.RUGEFR) (SOFT.RUSSIAN GERMAN FRENCH) J
004 LYT1534-006A INST BOOK(SOFT.AR.PE) (SOFT.ARABIC PERSIAN) J
004 LYT1534-007A INST BOOK(SOFT.EN.SCH) (SOFT.ENGLISH SIMPLIFIED CHINESE) D,H
014 ------------ WARRANTY CARD BT-56016-1 A,E
015 ------------ WARRANTY CARD BT-56017-1 A,E
016 BT-59021-6CAM SVC CENTER LIST B,F
017 YU30552-135 QUEST.CARD B,F
018 BT-59020-1 HOLOGRAM SEAL B,F
019 ------------ WARRANTY CARD BT-59019-1CAM B,F
021 LY35385-004A SHEET(ACC GUIDE)
022 LYT1621-006A SHEET(DVD.W.M) A,B,C,D,E,F,G,H
022 LYT1621-007A SHEET(DVD.W) J
023 LYT1621-008A SHEET(DVD.M) J
026 LYT1622-004A SHEET(ATT.DVD) J
026 LYT1622-005A SHEET(ATT.DVD) A,B,C,D,E,F,G,H
027 LYT1607-001A SHEET(ATT.)
051 LY30023-003A POLY BAG FOR YSK
052 LY35251-011A PACKING CASE PRODUCTION A,C,E,G,J
052 LY35251-015A PACKING CASE PRODUCTION B,D,F,H
053 LY21420-001A CUSHION
054 QPA02503505P POLY BAG ACC. 25cm x 35cm
055 QAM0508-001 A/V CABLE FILTER
056 QQR0918-004 CORE FILTER AV
057 QAM0719-001 USB CABLE
058 QQR0491-004 CORE FILTER USB 1T
059 QQR0491-004 CORE FILTER S 1T
 060 LY21104-001E AC ADAPTER AP-V14E A,D,E,H
 060 LY21104-002C AC ADAPTER AP-V14A J
 060 LY21104-003D AC ADAPTER AP-V14AC B,F
 060 LY21343-001B AC ADAPTER AP-V17E C,G
061 QQR0917-004 CORE FILTER DC
062 LY21430-002A REMOTE CTL UNIT RM-V730US
 063 LY34647-002B BATTERY PACK BN-VF707U
064 LY21397-002A SHOULDER STRAP
065 LY33693-002A CAP(HOOD)ASSY
068 LY45161-002A-ML LABEL JPN
 069 QMPH040-190-JR POWER CORD AS/NZS 1.9m BLACK A,E
 069 QMPL270-190-JR POWER CORD CEE 1.9m BLACK J
 069 QMPS260-190-JR POWER CORD CCC 1.9m BLACK B,F
 072 QMPL270-190-JR POWER CORD CEE 1.9m BLACK D,H
 073 QAM0001-001 CONVERSION PLUG FIX AC CO. D,H
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
PW1 LYA10072-03B MAIN BOARD ASSY
IC121 NAL0035-001X SHOCK SENSOR
IC171 KSM-2003LN2E IR DETECT UNIT
IC1001 MN102H60GJD IC(MICRO C ROM) MASK
IC1001 or MN102HF60GJD IC(MICRO C ROM) MP FLASH
IC1002 RS5C314-X IC
IC1003 S-80827CNNB-G-W IC
IC1004 SN74AHC1G08DC-X IC
IC1004 or 74AHC1G08GW-X IC
IC1004 or TC7SH08FU-X IC(DIGITAL)
IC1005 SN74AHC1G04DC-X IC
IC1005 or TC7SH04FU-X IC(DIGITAL)
IC1007 TC75S56FU-X IC
IC1007 or NJU7108F3-X IC
IC2201 AK4660VQ IC 48P0.5
IC2201 or AK4664VQ IC
IC3001 UPD61152F1-A03 IC(MICRO C ROM)
IC3002 K4S28323LF-HN75 IC 128M 32BIT
IC3201 JCP8075 IC
IC3202 MB90099PFV139EX IC(MICRO C ROM)
IC3204 R1100D251C-X IC
IC3701 BH7612FV-X IC
IC4001 SIP1280ISD-DVA3 IC
IC4301 SP32J55BFI12D40 IC(MICRO C ROM) 4M FLASH
IC4302 39VF1674CB3KF40 IC(MICRO C ROM) 2M FLASH
IC4303 K4S56323LF-HN75 IC 256M FBGA
IC4304 R1114N251B-X IC SREG2.5V
IC4501 JCY0209-2 IC
IC4502 M95320-WDW6-X IC ST EEPROM
IC4502 or AT25320A-10TU-X IC ATMEL EEPR
IC4901 JCY0223-X IC
IC8301 JCY0225 IC EPSON
IC8302 TPS2055AD-X IC USB POWER
IC8303 R1114N181B-X IC SREG 1.8V
Q171 RPM-22PB PHOTO TRANSISTOR
Q201 2SA1577/QR/-X TRANSISTOR
Q201 or BC807-25W-X TRANSISTOR
Q202 UMX1N-W PAIR TRANSISTOR
Q202 or PUMX1-W PAIR TRANSISTOR
Q202 or BC847S-X PAIR TRANSISTOR
Q202 or XP4501-W TRANSISTOR
Q1001 DTC124EE-X DIGI TRANSISTOR
Q1002 2SC4617/RS/-X TRANSISTOR
Q1002 or 2SD2216J/RS/-X TRANSISTOR
Q1002 or BC847BT-X TRANSISTOR
Q1003 DTA124EE-X DIGI TRANSISTOR
Q1004 2SC5658/QRS/-X TRANSISTOR
Q1005 2SJ347-X MOS FET
Q1006 DTA124EE-X DIGI TRANSISTOR
Q2202 UMX18N-W PAIR TRANSISTOR
Q2401 2SC4617/QR/-X TRANSISTOR
Q2401 or BC847BT-X TRANSISTOR
Q2403 2SC4617/QR/-X TRANSISTOR
Q2403 or BC847BT-X TRANSISTOR
Q3202 2SC4617/QR/-X TRANSISTOR
Q3202 or BC847BT-X TRANSISTOR
Q3701 PUMZ1-W PAIR TRANSISTOR
Q3701 or UMZ1N-W PAIR TRANSISTOR
Q3701 or XP4601-W TRANSISTOR
Q4001 2SC4617/RS/-X TRANSISTOR
Q4001 or BC847BT-X TRANSISTOR
Q4001 or 2SD2216J/RS/-X TRANSISTOR
Q7801 UMX1N-W PAIR TRANSISTOR
Q7801 or BC847S-X PAIR TRANSISTOR
Q7801 or PUMX1-W PAIR TRANSISTOR
Q7801 or XP4501-W TRANSISTOR
Q7802 UMX1N-W PAIR TRANSISTOR
Q7802 or BC847S-X PAIR TRANSISTOR
Q7802 or PUMX1-W PAIR TRANSISTOR
Q7802 or XP4501-W TRANSISTOR
Q7803 UMX1N-W PAIR TRANSISTOR
Q7803 or BC847S-X PAIR TRANSISTOR
Q7803 or PUMX1-W PAIR TRANSISTOR
Q7803 or XP4501-W TRANSISTOR
MODEL MARK
A
B
C
GZ-MG67AA
GZ-MG67AC
GZ-MG67AG
MODEL MARK
D
E
F
GZ-MG67AH
GZ-MG77AA
GZ-MG77AC
MODEL MARK
G
H
J
GZ-MG77AG
GZ-MG77AH
GZ-MG77AS
