JVC GZ-MG67AA Service Manual

(No.YF147)3-13
OPE BOARD ASSEMBLY <04>
IC5952 NAL0038-001X GYRO SENSOR
D5001 or MA111-X SI DIODE
C4104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4105 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4106 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4107 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4108 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4109 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C4110 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4112 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4113 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4114 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4115 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C4116 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C4117 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4118 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4122 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C5001 NBZ0018-106X TA E CAPACITOR 10uF 20V M
C5002 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5003 NBP21CM-106X TA E CAPACITOR 10uF 16V M
C5004 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5005 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5006 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5007 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C5008 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5009 NCJ20JK-106X-D C CAPACITOR 10uF 6.3V K
C5010 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5011 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5012 NCJ20JK-106X-D C CAPACITOR 10uF 6.3V K
C5014 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5015 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5016 NCB21HK-334X C CAPACITOR 0.33uF 50V K
C5017 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C5018 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5019 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5801 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C5806 NCBA1CK-103W C CAPACITOR 0.01uF 16V K
C5807 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C5808 NCBA1HK-331W C CAPACITOR 330pF 50V K
C5809 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C5810 NCBA1HK-331W C CAPACITOR 330pF 50V K
C5812 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5813 NCBA1HK-331W C CAPACITOR 330pF 50V K
C5851 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C5853 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5907 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C5908 NCBA1HK-331W C CAPACITOR 330pF 50V K
C5909 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C5910 NCBA1HK-331W C CAPACITOR 330pF 50V K
C5912 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
C5913 NCBA1HK-331W C CAPACITOR 330pF 50V K
R4102 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4103 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4104 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4105 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4106 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4107 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4108 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4109 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4110 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4111 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4112 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4113 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4114 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4116 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4117 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4118 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4119 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4120 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4121 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4122 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4123 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4124 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R4125 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R4126 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4127 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4128 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R4149 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R4151 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R5001 NRSA6AJ-104W MG RESISTOR 100k
Ω 1/16W J
R5002 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R5003 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5004 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5005 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5006 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5007 NRSA6AJ-101W MG RESISTOR 100 Ω 1/16W J
R5008 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5009 NRSA6AJ-470W MG RESISTOR 47 Ω 1/16W J
R5010 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5011 NRSA6AJ-100W MG RESISTOR 10 Ω 1/16W J
R5012 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5805 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R5806 NRSA6AJ-474W MG RESISTOR 470k Ω 1/16W J
R5807 NRSA6AJ-183W MG RESISTOR 18k Ω 1/16W J
R5808 NRSA6AJ-105W MG RESISTOR 1M
Ω 1/16W J
R5811 NRSA6AJ-123W MG RESISTOR 12k
Ω 1/16W J
R5812 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5816 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5817 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5818 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R5819 NRSA6AD-104W MG RESISTOR 100k Ω 1/16W D
R5820 NRSA6AD-103W MG RESISTOR 10k Ω 1/16W D
R5905 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R5906 NRSA6AJ-474W MG RESISTOR 470k Ω 1/16W J
R5907 NRSA6AJ-183W MG RESISTOR 18k Ω 1/16W J
R5908 NRSA6AJ-105W MG RESISTOR 1M Ω 1/16W J
R5911 NRSA6AJ-123W MG RESISTOR 12k Ω 1/16W J
R5912 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5915 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5917 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R5918 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R5919 NRSA6AD-104W MG RESISTOR 100k Ω 1/16W D
R5920 NRSA6AD-103W MG RESISTOR 10k Ω 1/16W D
L4101 NQR0006-001X FERRITE BEADS
L4102 NQR0006-001X FERRITE BEADS
L5001 NQL38DK-100X P COIL 10uH K
L5002 NQL38DK-100X P COIL 10uH K
L5003 NQL38DK-100X P COIL 10uH K
L5004 NQR0129-002X FERRITE BEADS
L5801 NQR0129-002X FERRITE BEADS
L5851 NQR0129-002X FERRITE BEADS
CN801 QGB0801L2-30X CONNECTOR CCD B-B (1-30)
CN802 QGF0309F2-53X CONNECTOR
KIN MAIN FFC/FPC (1-53)
CN803 QGA1002F1-04X CONNECTOR MAIN W-B (1-4)
TP4101 NNZ0094-001X EARTH TERMINAL
X5001 NAX0674-001X CXO 72.000MHZ
OT1 QAL0808-001 FPC CDS-MAIN
WR1 WJJ0689-001A-E E-SI C WIRE C-C ENB -MAIN
 Symbol No. Part No. Part Name Description Local
PW1 LYA10069-02C1 OPE BOARD ASSY
D401 SML-A12UT-X LED POW/CHG
D402 SMLA12BC4T-X LED DRV_ACCESS
D403 MA8068-X Z DIODE LCD_OPN SW
D403 or UDZS6.8B-X Z DIODE LCD_OPN SW
D404 SML-A12MT-X LED USB_HOST
D452 MA8068-X Z DIODE
D452 or UDZS6.8B-X Z DIODE
C451 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C452 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C455 NCB31EK-103X C CAPACITOR 0.01uF 25V K
R401 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GZ-MG67AA
GZ-MG67AC
GZ-MG67AG
MODEL MARK
D
E
F
GZ-MG67AH
GZ-MG77AA
GZ-MG77AC
MODEL MARK
G
H
J
GZ-MG77AG
GZ-MG77AH
GZ-MG77AS
