MONITOR BOARD ASSEMBLY <06>
R6009 NRSA6AD-333W MG RESISTOR 33k Ω 1/16W D
R6010 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6012 NRSA6AJ-564W MG RESISTOR 560k Ω 1/16W J
R6014 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R6015 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R6016 NRSA6AJ-104W MG RESISTOR 100k
Ω 1/16W J
R6017 NRSA6AJ-514W MG RESISTOR 510k
Ω 1/16W J
R6018 NRSA6AJ-184W MG RESISTOR 180k Ω 1/16W J
R6019 NRSA6AJ-824W MG RESISTOR 820k Ω 1/16W J
R6021 NRSA6AJ-474W MG RESISTOR 470k Ω 1/16W J
R6022 NRSA6AJ-104W MG RESISTOR 100k Ω 1/16W J
R6034 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R6102 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6103 NRSA6AJ-822W MG RESISTOR 8.2k Ω 1/16W J
R6104 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R6109 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R6111 NRSA6AD-473W MG RESISTOR 47k Ω 1/16W D
R6112 NRSA6AD-822W MG RESISTOR 8.2k Ω 1/16W D
R6203 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R6204 NRSA6AJ-822W MG RESISTOR 8.2k Ω 1/16W J
R6205 NRSA6AD-823W MG RESISTOR 82k
Ω 1/16W D
R6206 NRSA6AD-363W MG RESISTOR 36k
Ω 1/16W D
R6301 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R6302 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J
R6303 NRSA6AJ-822W MG RESISTOR 8.2k Ω 1/16W J
R6304 NRSA6AD-303W MG RESISTOR 30k Ω 1/16W D
R6305 NRSA6AD-133W MG RESISTOR 13k Ω 1/16W D
R6306 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6310 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R6311 NRSA6AJ-185W MG RESISTOR 1.8M Ω 1/16W J
R6313 NRSA6AJ-102W MG RESISTOR 1k Ω 1/16W J
R6401 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J
R6402 NRSA6AD-123W MG RESISTOR 12k Ω 1/16W D
R6403 NRSA6AJ-822W MG RESISTOR 8.2k Ω 1/16W J
R6404 NRSA6AD-562W MG RESISTOR 5.6k Ω 1/16W D
R6405 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R6406 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R6407 NRSA6AJ-185W MG RESISTOR 1.8M Ω 1/16W J
R6409 NRSA6AJ-102W MG RESISTOR 1k Ω 1/16W J
R6412 NRSA6AJ-185W MG RESISTOR 1.8M Ω 1/16W J
R6502 NRSA6AD-104W MG RESISTOR 100k Ω 1/16W D
R6503 NRSA6AD-913W MG RESISTOR 91k Ω 1/16W D
R6504 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J
R6505 NRSA6AJ-333W MG RESISTOR 33k Ω 1/16W J
R6507 NRSA6AJ-754W MG RESISTOR 750k Ω 1/16W J
R6509 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6512 NRSA6AJ-473W MG RESISTOR 47k Ω 1/16W J
R6513 NRSA6AJ-272W MG RESISTOR 2.7k Ω 1/16W J
R6702 NRV142F-R20X CMF RESISTOR 0.2 Ω 1/4W F
R6703 NRSA6AJ-105W MG RESISTOR 1M
Ω 1/16W J
R6704 NRSA6AJ-105W MG RESISTOR 1M Ω 1/16W J
R6708 NRSA6AD-133W MG RESISTOR 13k
Ω 1/16W D
R6709 NRSA6AD-104W MG RESISTOR 100k
Ω 1/16W D
R6710 NRSA6AJ-124W MG RESISTOR 120k Ω 1/16W J
R6712 NRSA6AJ-561W MG RESISTOR 560
Ω 1/16W J
R6713 NRSA6AJ-224W MG RESISTOR 220k
Ω 1/16W J
R6714 NRSA6AJ-472W MG RESISTOR 4.7k Ω 1/16W J
R6715 NRSA6AD-103W MG RESISTOR 10k
Ω 1/16W D
R6716 NRSA6AJ-822W MG RESISTOR 8.2k Ω 1/16W J
R6717 NRSA6AD-393W MG RESISTOR 39k
Ω 1/16W D
R6718 NRSA6AJ-0R0W MG RESISTOR 0
Ω 1/16W J
R6719 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6802 NRSA6AJ-472W MG RESISTOR 4.7k
Ω 1/16W J
R6803 NRSA6AJ-102W MG RESISTOR 1k
Ω 1/16W J
L6101 NQL52EM-390X COIL 39uH M
L6201 NQL52EM-680X COIL 68uH M
L6301 NQL52EM-390X COIL 39uH M
L6401 NQL52EM-390X COIL 39uH M
L6501 NQL52EM-221X COIL 220uH M
L6502 NQL38DK-100X P COIL 10uH K
L6701 NQL52EM-470X COIL 47uH M
L6801 NQL79GM-470X COIL 47uH M
CN6001 QGF0508F3-53X CONNECTOR KIN MAIN FFC/FPC (1-53)
CN6002 QGF0534F2-06X CONNECTOR KIN TRIG FFC/FPC (1-6)
 F6001 NMFZ007-2R5X-K FUSE 2.5A 24V
 F6002 NMFZ007-2R5X-K FUSE 2.5A 24V
 Symbol No. Part No. Part Name Description Local
 F6301 NMFZ007-1R25X-K FUSE 1.25A 32V
 F6501 NMFZ007-R80X-K FUSE 0.8A 32V
J601 QNA0039-001 DC JACK DC JACK
BT1 LY35291-001A BATT.TERMINAL BATT TERMI
OT1 QAL0782-002 FPC TO MAIN
 Symbol No. Part No. Part Name Description Local
PW2 LYA10069-01B2 MONITOR BOARD ASSY
IC7601 DN8797MS-X IC
Q7702 UMD3N-W DIGI TRANSISTOR
Q7703 UMX1N-W PAIR TRANSISTOR
Q7703 or PUMX1-W PAIR TRANSISTOR
Q7703 or BC847S-X PAIR TRANSISTOR
Q7703 or KTC801U/G/-X PAIR TRANSISTOR
Q7703 or RT3CLLM/EF/-X PAIR TRANSISTOR
C7602 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C7603 NCB31CK-105X C CAPACITOR 1uF 16V K
C7604 NCB31CK-105X C CAPACITOR 1uF 16V K
C7605 NCB31CK-105X C CAPACITOR 1uF 16V K
C7607 NCB11EK-105X C CAPACITOR 1uF 25V K
C7608 NCB31CK-105X C CAPACITOR 1uF 16V K
C7609 NCB11EK-105X C CAPACITOR 1uF 25V K
C7610 NCB11EK-105X C CAPACITOR 1uF 25V K
C7611 NCB11EK-105X C CAPACITOR 1uF 25V K
C7612 NCB11EK-105X C CAPACITOR 1uF 25V K
C7613 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C7614 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C7703 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7704 NCB31EK-104X C CAPACITOR 0.1uF 25V K
R7501 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R7502 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R7503 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R7601 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7603 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7605 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7606 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7607 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R7608 NRSA63J-106X MG RESISTOR 10M Ω 1/16W J
R7609 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7610 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7703 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R7705 NRSA63J-911X MG RESISTOR 910
Ω 1/16W J
R7706 NRSA63J-200X MG RESISTOR 20 Ω 1/16W J
L7602 NQL38DK-101X P COIL 100uH K
CN7601 QGF0534F2-12X CONNECTOR
KIN OPE FFC/FPC (1-12)
CN7602 QGF0534F2-12X CONNECTOR KIN OPE FFC/FPC (1-12)
CN7603 QGF0534F2-36X CONNECTOR KIN LCD FFC/FPC (1-36)
CN7701 QGF0534F2-06X CONNECTOR LED BL FFC/FPC (1-6)
S7501 NSW0288-001X TACT SWITCH CROSSKEY
S7502 NSW0198-001X TACT SWITCH MENU
OT1 QAL0687-001 FPC
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
GZ-MG67AA
GZ-MG67AC
GZ-MG67AG
MODEL MARK
D
E
F
GZ-MG67AH
GZ-MG77AA
GZ-MG77AC
MODEL MARK
G
H
J
GZ-MG77AG
GZ-MG77AH
GZ-MG77AS
