3.2.2 ASSEMBLY/DISASSEMBLY OF CABINET PARTS AND ELECTRICAL PARTS
z Disassembly procedure
NOTE2a:
During the procedure, leave the GRIP BELT removed from
the hook.
NOTE2b:
When removing the HDD COVER ASSY, leave the JACK
COVER (DC) released.
NOTE2c:
During the procedure, be careful not to damage the tabs.
NOTE2d:
When removing the HDD COVER ASSY, be careful in han-
dling as the HDD may come off.
NOTE3a:
During the procedure, be careful in handling the HDD. Make
sure not to give any shock to the HDD.
NOTE3b:
When attaching the HDD, check the positions of the marks,
and be careful with the GEL lift.
NOTE5:
The screw (No.12) is located under the JACK COVER
(REAR).
NOTE6:
Do not disassemble the ZOOM UNIT if not needed as the
SHIELD (ZOOM) is attached to the terminals.
NOTE7:
When removing the REAR UNIT, be careful in handling as
the JACK COVER (REAR) comes off together.
NOTE11a:
Remove the screw (No.28), which tightens up the FPC, be-
fore connecting/ disconnecting the FPC to/ from the connec-
tor.
NOTE11b:
When attaching the two switches (POWER, MODE), be
careful with the attachment locations. Attach the levers and
switches fixed to one direction as they can be fixed (except
the MODE switch lever). After the attachment, check the op-
eration by moving the switch levers.
NOTE11c:
When attaching the SPEAKER WIRE, be careful in the wir-
ing and not to catch the WIRE in between.
NOTE14:
Refer to 3.2.3 ASSEMBLY/DISASSEMBLY OF [14] MONI-
TOR ASSEMBLY for the disassembly of the MONITOR AS-
SY.
NOTE15:
When attaching the SPEAKER, be careful with the attach-
ment location. Attach the OPE BOARD ASSY first, and then
follow the figure for the SPKEAKER wiring.
NOTE18:
During the procedure, be careful to avoid electric shock
caused by the STROBE CAPACITOR.
NOTE19:
When attaching the MAIN BOARD ASSY, make sure to in-
sert the corner of the MAIN BOARD ASSY into the slit of the
FRAME ASSY.
NOTE20:
Refer to 3.2.4 ASSEMBLY/DISASSEMBLY OF [20] OP
BLOCK ASSEMBLY/CCD BOARD ASSEMBLY.
z Destination of connectors
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
CA1
FA1
FA2
FA3
FA4
FA5
UA1
FA6
UA2
UA3
UA4
UA5
FA7
FA8
FA9
FA10
-
NOTE2a,b,c,d
NOTE3a,b
-
NOTE5
NOTE6
NOTE7
-
-
-
NOTE11a,b,c
-
-
NOTE14
NOTE15
-
-
NOTE18
NOTE19
NOTE20
STEP
No.
PART NAME
Fig.
No.
POINT NOTE
BOTTOM COVER ASSY
HDD COVER ASSY
HDD
HDD CASE ASSY
TOP COVER(ZOOM)
ZOOM UNIT
REAR BOARD ASSY
MONI.LOCK CASE ASSY
COVER(HINGE-M)
UPPER ASSY
OPE BOARD ASSY
TOP COVER(U-M)ASSY
POWER SW ASSY
MONITOR ASSY
SPEAKER
FRONT COVER ASSY
MIC
STROBE UNIT
MAIN BOARD ASSY
OP BLOCK ASSY
3(S1),3(L1)
GRIP BELT,2(S2),
JACK COVER(DC),L2a,b,c,d
CN3
3(S4a),3(S4b)
CN5,JACK COVER(REAR),S5,L5a,b
SHIELD(ZOOM),2(S6),2(L6)
4(S7),L7a,JACK COVER(REAR),
CN7a,CN7b,L7b,REAR UNIT
2(S8),2(L8)
2(S9),L9
S10,L10,SHIELD(FRAME),
CN10,3(S10)
S11a,INTERRUPTER,
S11b,CN11a,b,3(S11b)
2(S12),2(L12)
2(S13),2(L13)
2(S14),2(L14)
4(S15),L15a,b,BKT(UPPER)
CN16,3(S16)
2(S17),L17,BKT(MIC-M)
CN18,2(S18),L18
CN19a,b,c,2(S19)
2(S20),SHIELD M ASSY,
3(S20),2(L20)
CN.
No.
PIN
No.
CONNECTOR
CN3 HDD - MAIN CN102 40
CN5 ZOOM UNIT - MAIN CN104 6
CN7a REAR CN6001 MAIN CN103 53
CN7b TRIG SW - REAR CN6002 6
CN10 OPE CN401 MAIN CN101 50
CN11a OPE CN402 MONITOR CN7601/7602 24,12/12
CN11b OPE CN403 SPEAKER - 2
CN16 MIC - MAIN CN107 4
CN18 STROBE UNIT - MAIN CN112 14
CN19a CDS CN803 MAIN CN113 4
CN19b CDS CN802 MAIN CN105 53
CN19c OP BLOCK - MAIN CN106 24
To Next Page
