(No.YF147)1-3

SECTION 1

PRECAUTION

Please refer to "GZ-MG67EX No.YF139" about this section.

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

2.1 DIFFERENCE LIST

The following table indicate main different points between models GZ-MG67EX, GZ-MG67AA, GZ-MG67AC, GZ-MG67AG,

GZ-MG67AH, GZ-MG77AA, GZ-MG77AC, GZ-MG77AG, GZ-MG77AH and GZ-MG77AS.

SECTION 3

DISASSEMBLY

Please refer to "GZ-MG67EX No.YF139" about this section.

SECTION 4

ADJUSTMENT

Please refer to "GZ-MG67EX No.YF139" about this section.

SECTION 5

TROUBLESHOOTING

Please refer to "GZ-MG67EX No.YF139" about this section.

MODEL GZ-MG67EX GZ-MG67AA GZ-MG67AC GZ-MG67AG GZ-MG67AH

HDD(BUILT-IN) 20GB 20GB 20GB 20GB 20GB

USB MASS STORAGE CLASS 2.0(OUT only) 2.0 2.0 2.0 2.0

AC ADAPTER AP-V17E AP-V14E AP-V14AC AP-V17E AP-V14E

AC CORD NO YES(AS/NZS Plug) YES(CCC Plug) NO YES(CEE Plug)

CONVERSION PLUG NO NO NO NO YES(Fix to AC Cord)

MODEL GZ-MG77AA GZ-MG77AC GZ-MG77AG GZ-MG77AH GZ-MG77AS

HDD(BUILT-IN) 30GB 30GB 30GB 30GB 30GB

USB MASS STORAGE CLASS 2.0 2.0 2.0 2.0 2.0

AC ADAPTER AP-V14E AP-V14AC AP-V17E AP-V14E AP-V14A

AC CORD YES(AS/NZS Plug) YES(CCC Plug) NO YES(CEE Plug) YES(CEE Plug)

CONVERSION PLUG NO NO NO YES(Fix to AC Cord) NO
