— 3 —
Buttons, Connectors and Indicators
Front Panel
Rear Panel
Cassette loading slot
VIDEO/AUDIO
input connectors
Display panel
VCR mode indicator
Play indicator
Record indicator
Timer mode indicator
Channel and auxiliary input/Clock time
Remote
sensor
S-VHS mode indicator
S-VIDEO
AC power cord
Lithium battery compartment
