3-4(No.YD023)
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
 501 LP10492-018A FRONT PANEL ASSY A
 501 LP10492-017A FRONT PANEL ASSY B
 501 LP10492-016A FRONT PANEL ASSY C
501A LP21188-002A CASSETTE DOOR
501B PQ46448 TORSION SPRING
 502 LP10488-002C TOP COVER
503 QYSBSG3006NA TAP SCREW M3 x 6mm TOP SIDE(x2)
504 QYSBSG3006NA TAP SCREW M3 x 6mm TOP REAR(x6)
505 PDV2539B DRUM FINAL ASSY A
505 PDV2531D DRUM FINAL ASSY B,C
506 QYTDSF2608ZA TAP SCREW M2.6 x 8mm DISPLAY/OPERATION JACK(x9)
507 LP31391-001A SPECIAL SCREW FRONT PANEL(x2)
508 LP21190-002A FITTING
 509 LP41077-001A LABEL(CAUTION)
510 QYSPSPD3008ZA SCREW M3 x 8mm DRUM(x3)
 511 LP10489-001B BOTTOM CHASSIS
 512 QMPR680-177-JC POWER CORD 1.77m BLACK A
 512 QMPR720-177-JD POWER CORD 1.77m BLACK B,C
 514 LP30002-0F1A SPACER
515 LP31391-002A SPECIAL SCREW MECHANISM(x3)
516 LP31391-001A SPECIAL SCREW HOUSING
517 LP31391-001A SPECIAL SCREW MAIN(x3)
518 QYTDSF3008MA TAP SCREW M3 x 8mm JACK COVER(x4)
 519 LP21178-019A REAR COVER
520 QYSBSG3006MA TAP SCREW M3 x 6mm REAR COVER
521 LP31348-001A FOOT (x2)
560 LP21177-001B BRACKET(DVD)
561 LP31391-001A SPECIAL SCREW BRACKET(DVD)(x3)
562 LP30002-0E5A SPACER (x2)
563 LP31392-001A BRACKET
564 QYSDSF2608ZA TAP SCREW M2.6 x 8mm DVD
565 QYSBSG3010ZA TAP SCREW M3 x 10mm DVD(x3)
WR1 QUQ112-2212CG FFC WIRE DISPLAY/OPERATION CN7003-MAIN CN3102
WR2 QUQ112-1010CG FFC WIRE JACK CN7191-MAIN CN7103
WR3 QUQ210-1916CC FFC WIRE DVD UNIT CN501-MAIN CN7301
WR4 QUQ210-1716CC FFC WIRE DVD UNIT CN503-MAIN CN7302
WR5 QUQ210-0510CC FFC WIRE DVD UNIT CN1-MAIN CN8301
HR-XVC27UA
HR-XVC27UM
HR-XVC29UJ
A
B
C
MODEL
MARK
