3-12(No.YD023)
Electrical parts list
Main board
Block No. [0][3]
 Symbol No. Part No. Part Name Description Local
PW1 LPA10258-03B MAIN BOARD ASSY A
PW1 LPA10258-02B MAIN BOARD ASSY B
PW1 LPA10258-01B MAIN BOARD ASSY C
IC1 JCP8060-LSA IC A
IC1 JCP8060-NVA IC B,C
 IC2201 AN3663FBP IC
IC3001 HD6432199RB13F IC(MCU) MASK A
IC3001 HD6432199RB11F IC(MCU) MASK B,C
IC3002 IC-PST3427U-X IC
IC3003 LPN0927-001B-01 IC(EEPROM) *(REFER TO BELOW) A
IC3003 LPN0918-003B-02 IC(EEPROM) *(REFER TO BELOW) B
IC3003 LPN0918-002B-01 IC(EEPROM) *(REFER TO BELOW) C
IC5201 UTCTL431-T IC
IC5201 or MM1431AT-T IC
IC5201 or L5431-T IC
IC5201 or TL431/A/-T IC
IC5301 UTCTL431-T IC
IC5302 MM1565AF-X IC
IC7102 MM1507XN-X IC
IC7104 MM1623XF-X IC
IC7501 74VHCT08ASJ-X IC
IC8001 HA17558AF-X IC
IC8001 or RC4558D-X IC
IC8201 MN101C30AJF IC(MCU)
IC8201 or MN101CP30AJF IC(MCU)
IC8202 SN74HCT08APW-X IC
IC8301 LB1641 IC
Q7 2SC2412K/QRS/-X TRANSISTOR A
Q7 or 2SC3928A/QRS/-X TRANSISTOR A
Q7 or 2SD601A/QRS/-X TRANSISTOR A
Q8 2SC2412K/QRS/-X TRANSISTOR A
Q8 or 2SC3928A/QRS/-X TRANSISTOR A
Q8 or 2SD601A/QRS/-X TRANSISTOR A
Q9 2SC2412K/QRS/-X TRANSISTOR A
Q9 or 2SC3928A/QRS/-X TRANSISTOR A
Q9 or 2SD601A/QRS/-X TRANSISTOR A
Q10 2SC2412K/QRS/-X TRANSISTOR A
Q10 or 2SC3928A/QRS/-X TRANSISTOR A
Q10 or 2SD601A/QRS/-X TRANSISTOR A
Q202 2SD601A/QRS/-X TRANSISTOR
Q202 or
2SC2412K/QRS/-X TRANSISTOR
Q202 or
2SC3928A/QRS/-X TRANSISTOR
Q2001 2SD601A/QRS/-X TRANSISTOR
Q2001 or
2SC2412K/QRS/-X TRANSISTOR
Q2001 or
2SC3928A/QRS/-X TRANSISTOR
Q2002 2SD601A/QRS/-X TRANSISTOR
Q2002 or
2SC2412K/QRS/-X TRANSISTOR
Q2002 or
2SC3928A/QRS/-X TRANSISTOR
Q2003 UN211E-X DIGI TRANSISTOR
Q2003 or DTA144WKA-X TRANSISTOR
Q2003 or RT1P44HC-X DIGI TRANSISTOR
Q2051 2SD601A/QRS/-X TRANSISTOR
Q2051 or
2SC2412K/QRS/-X TRANSISTOR
Q2051 or
2SC3928A/QRS/-X TRANSISTOR
Q2052 2SB709A/QR/-X TRANSISTOR
Q2052 or 2SA1037AK/QR/-X TRANSISTOR
Q2052 or 2SA1530A/QR/-X SI TRANSISTOR
Q2053 UN221E-X TRANSTSTOR
Q2053 or DTC144WKA-X DIGI TRANSISTOR
Q2053 or RT1N44HC-X DIGI TRANSISTOR
Q2054 2SB709A/QR/-X TRANSISTOR
Q2054 or 2SA1037AK/QR/-X TRANSISTOR
Q2054 or 2SA1530A/QR/-X SI TRANSISTOR
Q2055 UN221E-X TRANSTSTOR
Q2055 or DTC144WKA-X DIGI TRANSISTOR
Q2055 or RT1N44HC-X DIGI TRANSISTOR
Q2201 UN211E-X DIGI TRANSISTOR
Q2201 or DTA144WKA-X TRANSISTOR
Q2201 or RT1P44HC-X DIGI TRANSISTOR
Q2202 UN221E-X TRANSTSTOR
Q2202 or DTC144WKA-X DIGI TRANSISTOR
Q2202 or RT1N44HC-X DIGI TRANSISTOR
Q2203 2SD601A/QRS/-X TRANSISTOR
Q2203 or 2SC2412K/QRS/-X TRANSISTOR
Q2203 or
2SC3928A/QRS/-X TRANSISTOR
Q2204 2SD601A/QRS/-X TRANSISTOR
Q2204 or
2SC2412K/QRS/-X TRANSISTOR
Q2204 or 2SC3928A/QRS/-X TRANSISTOR
Q3002 PTZ-NV16A IC(PHOTO SENSOR)
Q3004 2SD601A/QRS/-X TRANSISTOR
Q3004 or 2SC2412K/QRS/-X TRANSISTOR
Q3004 or 2SC3928A/QRS/-X TRANSISTOR
Q3005 2SD601A/QRS/-X TRANSISTOR
Q3005 or 2SC2412K/QRS/-X TRANSISTOR
Q3005 or 2SC3928A/QRS/-X TRANSISTOR
Q3007 UN221E-X TRANSTSTOR
Q3007 or DTC144WKA-X DIGI TRANSISTOR
Q3007 or RT1N44HC-X DIGI TRANSISTOR
Q3901 UN221E-X TRANSTSTOR
Q3901 or DTC144WKA-X DIGI TRANSISTOR
Q3901 or RT1N44HC-X DIGI TRANSISTOR
Q3902 UN221E-X TRANSTSTOR
Q3902 or DTC144WKA-X DIGI TRANSISTOR
Q3902 or RT1N44HC-X DIGI TRANSISTOR
Q4001 UN2211-X TRANSISTOR
Q4001 or DTC114EKA-X TRANSISTOR
Q4001 or RT1N141C-X DIGI TRANSISTOR
Q5101 2SK2632-CB14 POWER MOS FET
Q5102 2SD2144S/UV/-T TRANSISTOR
Q5103 2SB709A/QR/-X TRANSISTOR
Q5103 or 2SA1037AK/QR/-X TRANSISTOR
Q5103 or 2SA1530A/QR/-X SI TRANSISTOR
Q5306 2SD2144S/UV/-T TRANSISTOR
Q5307 UN211E-X DIGI TRANSISTOR
Q5307 or DTA144WKA-X TRANSISTOR
Q5307 or RT1P44HC-X DIGI TRANSISTOR
Q5309 UN2211-X TRANSISTOR
Q5309 or DTC114EKA-X TRANSISTOR
Q5309 or RT1N141C-X DIGI TRANSISTOR
Q5310 2SD1858/QR/-T TRANSISTOR
Q5311 2SC5739/QP/ TRANSISTOR
Q5315 2SD1858/QR/-T TRANSISTOR
Q6030 2SB709A/QR/-X TRANSISTOR
Q6030 or 2SA1037AK/QR/-X TRANSISTOR
Q6030 or 2SA1530A/QR/-X SI TRANSISTOR
Q7113 2SA1037AK/QR/-X TRANSISTOR
Q7113 or 2SB709A/QR/-X TRANSISTOR
Q7113 or 2SA1530A/QR/-X SI TRANSISTOR
Q8001 2SD601A/QRS/-X TRANSISTOR
Q8001 or
2SC2412K/QRS/-X TRANSISTOR
Q8001 or
2SC3928A/QRS/-X TRANSISTOR
Q8002 2SD601A/QRS/-X TRANSISTOR
Q8002 or
2SC2412K/QRS/-X TRANSISTOR
Q8002 or
2SC3928A/QRS/-X TRANSISTOR
Q8052 2SD601A/QRS/-X TRANSISTOR
Q8052 or
2SC2412K/QRS/-X TRANSISTOR
Q8052 or
2SC3928A/QRS/-X TRANSISTOR
Q8053 UN2111-X TRANSISTOR
Q8053 or DTA114EKA-X DIGI TRANSISTOR
Q8053 or RT1P141C-X DIGI TRANSISTOR
D201 1SS133-T2 DIODE
D2001 1SS133-T2 DIODE
D2001 or 1SS270A-T2 SI DIODE
D2251 1SS133-T2 DIODE
D2251 or 1SS270A-T2 SI DIODE
D3001 LNB2301L01VI LED
D3002 1SS133-T2 DIODE
D3002 or 1SS270A-T2 SI DIODE
D3003 RD33ES/B3/-T2 Z DIODE
D3003 or MTZJ33C-T2 Z DIODE
D3004 10EDB20-T2 SI DIODE
D3004 or 1A3G-T2 SI DIODE
D3005 10EDB20-T2 SI DIODE
D3005 or 1A3G-T2 SI DIODE
D3008 1SS133-T2 DIODE
 Symbol No. Part No. Part Name Description Local
HR-XVC27UA
HR-XVC27UM
HR-XVC29UJ
A
B
C
MODEL
MARK
*The VCR goes to jig RCU mode after replacing the EEPROM and the VCR does not accept some RCU command.
Therefore please set the VCR to the user RCU mode after replacing the EEPROM.
The method of setting the VCR to the user RCU mode is written on the service manual.
