(No.YD023)3-13
D3008 or 1SS270A-T2 SI DIODE
D4002 1SS133-T2 DIODE
D5001 S1WB/A/60-4102 BRIDGE DIODE
D5001 or S1WB/A/60-X BRIDGE DIODE
D5101 10ERB40-T2 FR DIODE
D5101 or AU01-T2 SI DIODE
D5102 10ERB40-T2 FR DIODE
D5102 or AU01-T2 SI DIODE
D5103 1SS133-T2 DIODE
D5103 or 1SS270A-T2 SI DIODE
D5105 1SS133-T2 DIODE
D5105 or 1SS270A-T2 SI DIODE
D5106 MTZJ33D-T2 Z DIODE
D5106 or RD33ES/B4/-T2 Z DIODE
D5201 PG104RS-T2 FR DIODE
D5201 or 10ERB20-T2 FR DIODE
D5201 or 1F4G-T2 FR DIODE
D5201 or AU01Z-T2 FR DIODE
D5201 or 1SR153-400-T2 FR DIODE
D5208 1S4-T2 SB DIODE
D5208 or AW04-T2 SB DIODE
D5208 or SBO40-T2 SB DIODE
D5209 PG104RS-T2 FR DIODE
D5209 or 10ERB20-T2 FR DIODE
D5209 or 1F4G-T2 FR DIODE
D5209 or AU01Z-T2 FR DIODE
D5209 or 1SR153-400-T2 FR DIODE
D5212 SB240-F26 SB DIODE
D5212 or RK14LF-B2 SBD
D5212 or 21DQ04-F SBD
D5213 1F4G-T2 FR DIODE
D5213 or 10ERB20-T2 FR DIODE
D5301 MTZJ15C-T2 Z DIODE
D5301 or RD15ES/B3/-T2 Z DIODE
D5305 MTZJ11C-T2 Z DIODE
D5305 or RD11ES/B3/-T2 Z DIODE
D5306 MTZJ5.6C-T2 Z DIODE
D5306 or RD5.6ES/B3/-T2 Z DIODE
D5310 MTZJ10B-T2 Z DIODE
D5310 or RD10ES/B2/-T2 Z DIODE
D6002 HZ30-2L-T2 Z DIODE
D6002 or HZ30-2LTD Z DIODE
D8001 1SS133-T2 DIODE
D8001 or 1SS270A-T2 SI DIODE
D8301 RD5.1ES/B2/-T2 Z DIODE
D8301 or MTZJ5.1B-T2 Z DIODE
PC3001 RPI-304J IC(PHOTO SENSOR)
PC3002 RPI-304J IC(PHOTO SENSOR)
 PC5101 PC123Y22FZ PHOTO COUPLER
C1 NDC31HJ-151X C CAPACITOR 150pF 50V J
C2 NDC31HJ-470X C CAPACITOR 47pF 50V J A
C2 NDC31HJ-330X C CAPACITOR 33pF 50V J B,C
C4 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C5 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C9 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C11 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C12 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C14 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C15 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C17 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C19 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C20 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C22 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C24 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C25 QEKJ1HM-335Z E CAPACITOR 3.3uF 50V M
C26 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C27 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C30 NCB31HK-561X C CAPACITOR 560pF 50V K A
C30 NCB31HK-331X C CAPACITOR 330pF 50V K B,C
C31 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C33 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C34 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C35 NCB31EK-103X C CAPACITOR 0.01uF 25V K
 Symbol No. Part No. Part Name Description Local
C36 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C37 NDC31HJ-4R0X C CAPACITOR 4pF 50V J
C40 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C41 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C43 QEKJ1HM-335Z E CAPACITOR 3.3uF 50V M
C44 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C45 NCB31CK-333X C CAPACITOR 0.033uF 16V K A
C45 NCB31EK-472X C CAPACITOR 4700pF 25V K B,C
C46 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C47 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C48 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C49 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C56 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C57 NCB31EK-103X C CAPACITOR 0.01uF 25V K A
C57 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z B,C
C58 NCB31EK-103X C CAPACITOR 0.01uF 25V K A
C58 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z B,C
C59 NCB31EK-103X C CAPACITOR 0.01uF 25V K A
C59 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z B,C
C60 NCB31EK-103X C CAPACITOR 0.01uF 25V K A
C60 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z B,C
C63 NCB31EK-103X C CAPACITOR 0.01uF 25V K A
C64 NCB31EK-103X C CAPACITOR 0.01uF 25V K A
C77 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C78 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C201 NDC31HJ-220X C CAPACITOR 22pF 50V J
C202 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C203 NCB31HK-102X C CAPACITOR 1000pF 50V K
C204 NCB31HK-681X C CAPACITOR 680pF 50V K
C205 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C206 NCB31HK-681X C CAPACITOR 680pF 50V K
C207 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C209 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C210 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C212 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C213 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C2001 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2002 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C2005 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2006 NCB31EK-682X C CAPACITOR 6800pF 25V K
C2007 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2008 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2009 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2010 NCB31HK-681X C CAPACITOR 680pF 50V K
C2011 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2012 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2051 NCB31HK-331X C CAPACITOR 330pF 50V K
C2052 QFV61HJ-823Z MF CAPACITOR 0.082uF 50V J
C2053 NCB31HK-472X C CAPACITOR 4700pF 50V K
C2054 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C2055 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2201 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2202 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2203 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2204 QEKJ0JM-336Z E CAPACITOR 33uF 6.3V M
C2205 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2206 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2207 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C2208 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C2209 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2210 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2211 QEKJ0JM-336Z E CAPACITOR 33uF 6.3V M
C2212 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C2214 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2215 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2218 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2219 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2220 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C2221 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C2222 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C2234 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2235 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2251 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C2252 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C2253 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C2254 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C2255 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C2256 NCB31EK-103X C CAPACITOR 0.01uF 25V K
 Symbol No. Part No. Part Name Description Local
HR-XVC27UA
HR-XVC27UM
HR-XVC29UJ
A
B
C
MODEL
MARK
