(No.YD023)3-15
R2201 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2202 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2205 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2206 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R2209 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R2210 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2211 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R2212 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R2213 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2214 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R2216 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R2218 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R2219 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2220 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2221 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R2222 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R2223 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R2224 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R2230 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R2231 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R2251 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2252 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R2255 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R2257 NRSA63J-684X MG RESISTOR 680k
Ω
1/16W J
R3033 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R3034 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R3043 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3045 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3046 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3047 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3048 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R3049 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R3050 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R3051 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3052 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3053 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3054 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3058 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3061 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R3062 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R3063 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3064 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3065 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R3069 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R3074 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3077 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3080 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3082 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3085 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R3089 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J A
R3098 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3099 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3101 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3201 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3202 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R3205 QRE141J-181Y C RESISTOR 180
Ω
1/4W J
R3207 QRE141J-183Y C RESISTOR 18k
Ω
1/4W J
R3208 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3209 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3210 NRSA63J-121X MG RESISTOR 120
Ω
1/16W J
R3211 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3212 QRE141J-474Y C RESISTOR 470k
Ω
1/4W J
R3213 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R3214 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3215 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3216 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3217 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3218 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3219 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3220 QRE141J-104Y C RESISTOR 100k
Ω
1/4W J
R3222 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3223 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3224 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3225 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3229 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R3234 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R3235 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R3236 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
Symbol No.
Part No. Part Name Description Local
R3243 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R3244 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R3246 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3248 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3256 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R4001 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R4003 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R4004 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R4005 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R4007 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4009 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4012 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R4015 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R4017 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5101 QRE141J-224Y C RESISTOR 220k
Ω
1/4W J
R5102 QRE141J-224Y C RESISTOR 220k
Ω
1/4W J
R5103 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R5104 QRG02GJ-683 OMF RESISTOR 68k
Ω
2W J
R5106 QRT01DJ-R27X MF RESISTOR 0.27
Ω
1W J
R5107 QRE121J-331Y C RESISTOR 330
Ω
1/2W J
R5108 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5109 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R5110 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5111 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5112 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5113 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R5201 QRE141J-221Y C RESISTOR 220
Ω
1/4W J
R5202 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5203 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5204 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R5205 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R5206 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R5311 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5312 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5313 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R5316 QRE141J-181Y C RESISTOR 180
Ω
1/4W J
R5317 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R5319 NRSA63J-560X MG RESISTOR 56
Ω
1/16W J
R5320 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R5321 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R5325 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5390 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R5392 QRL02DJ-391X OMF RESISTOR 390
Ω
2W J
R5393 QRL02DJ-391X OMF RESISTOR 390
Ω
2W J
R5394 QRL02DJ-391X OMF RESISTOR 390
Ω
2W J
R5395 QRL02DJ-391X OMF RESISTOR 390
Ω
2W J
R6020 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6021 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6030 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R6031 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R6050 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6051 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R6054 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R6055 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R6502 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R7134 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7135 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R7137 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R7154 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R7155 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7156 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7164 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R7165 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R7166 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R7173 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7174 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R7175 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7176 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R7177 NRSA63J-820X MG RESISTOR 82
Ω
1/16W J
R7179 NRSA63J-820X MG RESISTOR 82
Ω
1/16W J
R7183 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7184 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R7193 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7501 NRSA02J-100X MG RESISTOR 10
Ω
1/10W J
R7502 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R7503 NRSA63J-301X MG RESISTOR 300
Ω
1/16W J
R7504 NRSA63J-820X MG RESISTOR 82
Ω
1/16W J
R7506 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
HR-XVC27UA
HR-XVC27UM
HR-XVC29UJ
A
B
C
MODEL
MARK
