Additional preparation
Connecting methods
1 Connect the TV's VIDEO jack and the
device's VIDEO OUT (video output) jack
with a video cable.
If connecting a device to the TV with an
S-VIDEO cabel:
Connect the VCR's S-VIDEO OUT (S-VIDEO output)
connector and the TV's S-VIDEO connector with an
S-VIDEO cable, instead of connecting with a video
cable.
Note that the connection with a video cable will be
ignored in case you conect a VCR to the TV with both
video cable and S-VIDEO cable.
•In the VIDEO-1 terminal, the S-VIDEO connector is
indicated by "S".
If connecting a DVD player to the TV with
a component video cable:
Connect three jacks (Y/VIDEO, C
B
and C
R
) in the
VIDEO-3 terminal and the DVD player's COMPONENT
(component video output) jacks with a component
video cables, instead of connection with a video
cable.
Then set the VIDEO-3 SETTING to COMPONENT,
according to "VIDEO-3 SETTING" on page 22.
•This Television is compatible with the Progressive
video signal (525P signal). (When the component
video signal is input.)
If you have a DVD player that outputs Progressive
video signals (525P) as a component video signal,
then by attaching the device to the television with
a component video cable you can see the actual
images that are recorded on a DVD disc as an
original image source.
If connecting a device to the VIDEO-3/
COMPONENT terminal with a video cable
:
Connect the TV's Y/VIDEO jack and the device's
VIDEO OUT (video output) jack with a video cables.
Then set the VIDEO-3 SETTING to VIDEO according
to "VIDEO-3 SETTING" on page 22.
•In the VIDEO-4 terminal, the VIDEO jack is
indicated by "V".
2 Connect the TV's AUDIO jacks (L/MONO
and R) and the device's AUDIO OUT (au-
dio L/R output) jacks with an audio cable.
If the device's sound output is in mono:
Connect the device's AUDIO OUT jack and the TV's
L/MONO jack with an audio cable.
Connecting devices to the OUTPUT
terminal
The signals of the images and sound you are cur-
rently viewing with this TV are output through the
OUTPUT terminal. By connecting a VCR to the OUT-
PUT terminal, you can record the currently shown
image and sound to that VCR. To do this, connect the
VCR and OUTPUT terminal following the steps below.
1 Connect the VIDEO jack in the OUTPUT
terminal and the VCR's VIDEO IN (video
input) jack with a video cable.
2 Connect the AUDIO jacks (L and R) in the
OUTPUT terminal and the VCR's AUDIO
IN (audio L/R input) jacks with an audio
cable.
•When you turn off the TV, the signals from the
OUTPUT terminal are also turned off.
•The component signals input from the VIDEO-3/
COMPONENT terminal cannot be output through
the OUTPUT terminal.
Connecting Headphones
Connect the headphones with a stereo mini jack (of
3.5 mm in diameter) to the Headphone jack at the TV
front panel.
