1-20 (No.MA429<Rev.002>)
4.4 ERROR CODE
4.4.1 Mechanical Error Detail Codes
4.4.2 CD changer mechanism error code
Condition Details Error Code Detail Code
Disc Loading Error
(1) B1 Time Out After detecting SW1=L, it does not become SW2=L 09 0011
(2) B2 Time Out After detecting SW2=H, it does not become SW2=L 09 0012
(3) C1 Time Out After detecting SW2=L, it does not become SW2=H 09 0013
Eject Error
(1) B1 Time Out After detecting SW2=H, it does not become SW2=L 01 0021
(2) C2 Time Out After detecting SW2=L, it does not become SW2=H 01 0022
(3) B2 Time Out After detecting SW1=L, it does not become SW2=L
immediately after RESET and so on.
01 0023
(4) D0 Panel Close Disc can not be ejected due to closed panel. 01 0024
Forced Eject Error
(1) E1 Error SW1=H, SW2=L detected from NO DISC 01 0041
(2) E2 Error Detected SW1=L after RESET and then detected SW1=H 01 0042
(3) E3 Error Detected SW1=H after RESET 01 0043
(4) E4 Error Detected SW1=H after SW1=L 01 0044
(5) E5 Error Detected SW1=H after SW2=H→L 01 0045
(6) E6 Error Time Out for Loading after RESET 01 0046
(7) E7 Error Detected SW1=H after SW2=H→L→H 01 0047
(8) E8 Error Eject Key input while the procedure is not completed after
Forced Eject execution
01 0048
(9) Error Eject Key input during Disc is on the way and not completed 01 0049
Loading Waiting Error
(1) SW1=H or NO DISC
detection before Loading
Motor activation during
Disc is waiting at thewaiting location.
Disc is removed or NO DISC detection condition 09 0031
(2) SW2=L before Loading
Motor activation during
Disc is waiting at thewaiting location.
Disc is inserted 09 0032
Error contents Details Error code Detail code
Tray eject error Tray motor time over
1.TRAYINSW time over
(TRAYINSW:LTRAYOUTSW:H)
Tray motor does not operate. 03 0011
2.TRAYOUTSW time over
(TRAYINSW:HTRAYOUTSW:H)
Tray stops. 03 0012
3.TRAYINSW time over
(TRAYINSW:LTRAYOUTSW:L)
TRAYINSW NG etc. 03 0013
4.MAGIN SW:L→H Magazine is ejected while Tray is being ejected. 03 0014
Tray return error Tray motor time over
1.TRAYOUTSW time over
(TRAYINSW:HTRAYOUTSW:L)
Tray motor does not operate. 03 0016
2.TRAYINSW time over
(TRAYINSW:HTRAYOUTSW:H)
Tray stops. 03 0017
3.TRAYIN/OUTSW time over
(TRAYINSW:LTRAYOUTSW:L)
TRAYOUTSW NG etc. 03 0018
4.MAGIN SW:L→H Magazine is ejected while Tray is being returned. 03 0019
To Next Page
