JVC KD-A305J - Main Board

3-11
CD control board
Block No. [0][3]
Main board
Block No. [0][4]
Q604 2SA2174G-X TRANSISTOR
Q605 UN2222-X IC
Q607 2SA2174G-X TRANSISTOR
Q608 UN2222-X IC
Q610 2SA2174G-X TRANSISTOR
Q611 UN2222-X IC
D601 NSSM065T-X LED
D602 NSSM065T-X LED
D604 NSSM065T-X LED
D605 NSSM065T-X LED
D630 LHQ974/LM/-X LED
D631 LHQ974/LM/-X LED
D632 LHQ974/LM/-X LED
D650 MA8056/M/-X Z DIODE
D650 or UDZW5.6B-X Z DIODE
D661 MA111-X SI DIODE
D661 or 1SS355W-X DIODE
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-105X C CAPACITOR 1uF 16V K
C650 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C651 NBE21CM-106X TA E CAPACITOR 10uF 16V M
C661 NCB31CK-105X C CAPACITOR 1uF 16V K
C662 NDC31HJ-151X C CAPACITOR 150pF 50V J
C663 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C665 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C666 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C682 NCB31EK-104X C CAPACITOR 0.1uF 25V K
R601 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R607 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R609 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R610 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R611 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R612 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R613 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R614 NRSA63F-154X MG RESISTOR 150k
Ω 1/16W F
R615 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R618 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R630 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R631 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R634 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R636 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R637 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R638 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R644 NRSA63J-751X MG RESISTOR 750
Ω 1/16W J
R645 NRSA63J-751X MG RESISTOR 750
Ω 1/16W J
R646 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R647 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R648 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R649 NRSA63J-162X MG RESISTOR 1.6k
Ω 1/16W J
R651 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R656 NRS181J-471X MG RESISTOR 470
Ω 1/8W J
R657 NRS181J-471X MG RESISTOR 470
Ω 1/8W J
R658 NRS181J-751X MG RESISTOR 750
Ω 1/8W J
R660 NRS181J-394X MG RESISTOR 390k
Ω 1/8W J
R661 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R662 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R663 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R664 NRS181J-224X MG RESISTOR 220k
Ω 1/8W J
R665 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R666 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R667 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R681 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R682 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
J601 QNS0215-001 3.5 JACK A,B
J601 QNS0245-001 AUX JACK C,D,E,F,
G,H,I,J,K
JS686 QSW1231-002 ROTARY ENCODER
S601 NSW0124-001X TACT SW
 Symbol No. Part No. Part Name Description Local
S602 NSW0316-001X TACT SWITCH
S603 NSW0316-001X TACT SWITCH
S604 NSW0316-001X TACT SWITCH
S605 NSW0316-001X TACT SWITCH
S606 NSW0316-001X TACT SWITCH
S607 NSW0316-001X TACT SWITCH
S608 NSW0316-001X TACT SWITCH
S609 NSW0316-001X TACT SWITCH
S610 NSW0316-001X TACT SWITCH
S611 NSW0316-001X TACT SWITCH
 Symbol No. Part No. Part Name Description Local
Q101 2SC3928A/R/-X TRANSISTOR
Q101 or 2SD601A/R/-X TRANSISTOR
Q201 2SC3928A/R/-X TRANSISTOR
Q201 or 2SD601A/R/-X TRANSISTOR
Q301 PS1191RB22/BC/X PHOTO
TRANSISTOR
Q302 PS1191RB22/BC/X PHOTO
TRANSISTOR
D101 AN1105W21/AB/-X IR LED
D201 AN1105W21/AB/-X IR LED
R101 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R102 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R103 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R104 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R105 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R201 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R202 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R203 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R204 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R205 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
CN101 QGB2027LA-26X CONNECTOR B-B (1-26)
CN102 QGF0522F3-15W CONNECTOR FFC/FPC (1-15)
SW1 NSW0291-001X DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
 IC1 TEF6606T/V5-X IC
IC161 BD3700FV-X IC
 IC301 TB2926CHQ IC
IC381 NJM2160BV-X IC A
 IC501 LA6565-X IC
 IC521 MN6627945EE IC
IC581 NJM4565E-X IC
 IC701 MN101E16YFA1 IC
IC702 S-80824CNNB-G-W IC
IC702 or IC-PST3424U-X IC
IC801 74AHCT126PW-X IC
 IC901 AN34001A IC
IC981 NJM2878F4-15-X IC
Q341 IMX9-W PAIR TRANSISTOR
Q501 2SA1705/ST/-T TRANSISTOR
Q521 ISA1530AC1/R/-X TRANSISTOR
Q521 or 2SA2077-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q781 or UN2111-X TRANSISTOR
Q782 2SC3928A/QR/-X TRANSISTOR
Q782 or 2SC5845-X TRANSISTOR
Q784 RT1P141C-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
