3-10
Old Switch board
Block No. [0][2]
R528 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R529 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R535 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R536 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R537 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R538 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R540 NRSA63J-303X MG RESISTOR 30k
Ω
1/16W J
R541 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R542 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R543 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R544 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R545 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R546 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R547 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R548 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R549 NRS181J-562X MG RESISTOR 5.6k
Ω
1/8W J
R554 NRSA63J-4R7X MG RESISTOR 4.7
Ω
1/16W J
R556 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R558 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R559 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R565 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R566 NRS181J-100X MG RESISTOR 10
Ω
1/8W J
R583 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R584 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R585 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R586 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R587 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R588 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R591 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R592 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R593 NRS181J-223X MG RESISTOR 22k
Ω
1/8W J
R594 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R701 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R702 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R703 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R704 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R707 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R708 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J C,D,E,F,G,
H,I,J,K
R709 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J A,B
R712 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R714 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R716 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R717 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R718 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R719 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R720 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R723 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R726 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R727 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R731 NRS181J-104X MG RESISTOR 100k
Ω
1/8W J
R732 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R733 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R735 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R736 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R737 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R738 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R739 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R740 NRS181J-104X MG RESISTOR 100k
Ω
1/8W J
R746 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R747 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R752 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R753 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R754 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
R755 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R756 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R758 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R759 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R770 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J A
R770 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J B,C,D,E,F,
G,H , I,J, K
R771 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R772 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R773 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J A
R773 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J B,C,D,E,F,
G,H , I,J, K
Symbol No.
Part No. Part Name Description Local
R774 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R775 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R779 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R781 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R782 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R802 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R803 NRS181J-682X MG RESISTOR 6.8k
Ω
1/8W J
R804 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R807 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R808 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R809 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R810 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R811 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R812 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R814 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R819 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R851 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J C,D,E,F,G,
H,I,J,K
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω
1/10W J
R903 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R905 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J C,D,E,F,G,
H,I,J,K
R906 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J C,D,E,F,G,
H,I,J,K
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R976 NRSA02J-273X MG RESISTOR 27k
Ω
1/10W J
R977 NRSA02J-123X MG RESISTOR 12k
Ω
1/10W J
L1 NQL093K-R47X COIL 0.47uH K
L2 NQL093K-1R8X COIL 1.8uH K
L3 QQL213M-R22Z COIL 0.22uH M
L4 QQR1813-001 COIL
L5 QQL244J-561Z COIL 560uH J
L6 QQL244J-561Z COIL 560uH J
L7 QQL244J-4R7Z P COIL 4.7uH J
L8 QQL244J-4R7Z P COIL 4.7uH J
L9 NQL093K-R47X COIL 0.47uH K
L120 NQR0007-002X FERRITE BEADS
L121 NQR0007-002X FERRITE BEADS
L122 NQR0007-002X FERRITE BEADS
L701 QQL244J-4R7Z P COIL 4.7uH J
L702 QQL244J-4R7Z P COIL 4.7uH J
L901 QQR1852-001 CHOKE COIL
L901 or QQR0703-001 CHOKE COIL
CN501 QGB2027MD-26 CONNECTOR B-B (1-26)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0607-001 CAR CONNECTOR
J1 QNB0190-001 ANT TERMINAL
J321 QNN0832-001 PIN JACK A
J321 QNN0802-001 PIN JACK B,C,D,E,F,
G,H , I,J, K
J702 QNS0283-001 STEERING REMOTE A
J801 QNZ0095-001 CONNECTOR
S701 QSW0648-001Z TACT SWITCH
X1 QAX0928-001Z CRYSTAL
X521 QAX0930-001Z CRYSTAL
X701 QAX0667-001Z C RESONATOR 8.000MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC601 NCP5623DTBR2G-X IC
IC661 PTC6526LQ-L IC
IC681 NJL29H380A REMOCON RCV
Q601 2SC3928A/QR/-X TRANSISTOR
Q601 or 2SC5845-X TRANSISTOR
Q602 UNR9211G-X TRANSISTOR
Symbol No.
Part No. Part Name Description Local
