JVC KD-A305J - No.ma429<Rev

(No.MA429<Rev.002>)1-9
3.1.4 Removing the CD mechanism (See Fig.6)
(1) Remove the three screws J attaching the CD mechanism.
Fig.6
3.1.5 Removing the Switch board (See Fig.7)
(1) Remove the Volume knob.
(2) Remove the four screws K attaching the Rear cover.
(3) Disengage eleven hooks b engaged Rear cover.
Fig.7
JJ
J
KK hook b
hook b
