JVC KD-A305J - Page 50

3-14
Switch board
Block No. [0][5]
R718 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R719 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R720 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R723 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R726 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R727 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R731 NRS181J-104X MG RESISTOR 100k
Ω 1/8W J
R732 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R733 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R735 NRS181J-472X MG RESISTOR 4.7k
Ω 1/8W J
R736 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R737 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R738 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R739 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R740 NRS181J-104X MG RESISTOR 100k
Ω 1/8W J
R746 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R747 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R752 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R753 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R754 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
R755 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R756 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R758 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R759 NRS181J-222X MG RESISTOR 2.2k
Ω 1/8W J
R770 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J A
R770 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J B,C,D,E,F,G,
H,I,J,K,L
R773 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J A
R773 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J B,C,D,E,F,G,
H,I,J,K,L
R774 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R775 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R779 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R781 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R782 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R784 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R802 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R803 NRS181J-682X MG RESISTOR 6.8k
Ω 1/8W J
R804 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R807 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R808 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R809 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R810 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R811 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R812 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R814 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R819 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R851 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J C,D,E,F,G,H,I
,J,K
R901 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R902 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R903 NRS181J-472X MG RESISTOR 4.7k
Ω 1/8W J
R905 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J C,D,E,F,G,H,I
,J,K
R906 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J C,D,E,F,G,H,I
,J,K
R971 NRS181J-332X MG RESISTOR 3.3k
Ω 1/8W J
R976 NRSA02J-273X MG RESISTOR 27k
Ω 1/10W J
R977 NRSA02J-123X MG RESISTOR 12k
Ω 1/10W J
L1 NQL093K-R47X COIL 0.47uH K
L2 NQL093K-1R8X COIL 1.8uH K
L3 QQL213M-R22Z COIL 0.22uH M
L4 QQR1813-001 COIL
L5 QQL244J-561Z COIL 560uH J
L6 QQL244J-561Z COIL 560uH J
L7 QQL244K-4R7Z COIL 4.7uH K
L8 QQL244K-4R7Z COIL 4.7uH K
L120 NQR0007-002X FERRITE BEADS
L121 NQR0007-002X FERRITE BEADS
L122 NQR0007-002X FERRITE BEADS
L701 QQL244K-4R7Z COIL 4.7uH K
L702 QQL244K-4R7Z COIL 4.7uH K
L901 QQR1852-001 CHOKE COIL
L901 or QQR0703-001 CHOKE COIL
 Symbol No. Part No. Part Name Description Local
CN501 QGB2027MD-26 CONNECTOR B-B (1-26)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0607-001 CAR CONNECTOR
J1 QNB0190-001 ANT TERMINAL
J321 QNN0832-001 PIN JACK A
J321 QNN0802-001 PIN JACK B,C,D,E,F,G,
H,I,J,K,L
J702 QNS0283-001 STEERING
REMOTE
A
J801 QNZ0095-001 CONNECTOR
S701 QSW0648-001Z TACT SWITCH
X1 QAX0928-001Z CRYSTAL
X521 QAX0930-001Z CRYSTAL
X701 QAX0667-001Z C RESONATOR 8.000MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
IC601 NCP5623DTBR2G-X IC
IC661 PTC6526LQ-L IC
IC681 NJL29H380A REMOCON RCV A,B,C,D,E,F,
G,H,I,J,K
IC681 KSM-2003TN2M REMOCON RCV L
Q601 2SC3928A/QR/-X TRANSISTOR
Q601 or 2SC5845-X TRANSISTOR
Q602 UNR9211G-X TRANSISTOR
Q602 or DTC114EEB-X TRANSISTOR
Q604 2SA2174G-X TRANSISTOR
Q604 or 2SA1774/QR/-X TRANSISTOR
Q605 UN2222-X IC
Q605 or DTD143EK-X TRANSISTOR
Q607 2SA2174G-X TRANSISTOR
Q607 or 2SA1774/QR/-X TRANSISTOR
Q608 UN2222-X IC
Q608 or DTD143EK-X TRANSISTOR
Q610 2SA2174G-X TRANSISTOR
Q610 or 2SA1774/QR/-X TRANSISTOR
Q611 UN2222-X IC
Q611 or DTD143EK-X TRANSISTOR
D601 NSSM065T-X LED
D602 NSSM065T-X LED
D604 NSSM065T-X LED
D605 NSSM065T-X LED
D630 LHQ974/LM/-X LED
D631 LHQ974/LM/-X LED
D632 LHQ974/LM/-X LED
D650 MA8056/M/-X Z DIODE
D650 or UDZW5.6B-X Z DIODE
D661 MA111-X SI DIODE
D661 or 1SS355W-X DIODE
C604 NCB31CK-105X C CAPACITOR 1uF 16V K
C650 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C651 NBE21CM-106X TA E CAPACITOR 10uF 16V M
C661 NCB31CK-105X C CAPACITOR 1uF 16V K
C662 NDC31HJ-151X C CAPACITOR 150pF 50V J
C663 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C665 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C666 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C682 NCB31EK-104X C CAPACITOR 0.1uF 25V K
R601 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R607 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R609 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R610 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
