DVD-ROM No.SML2009Q1
SCHEMATIC DIAGRAMS
CD RECEIVER
No.MA429SCH<Rev.002>
2009/8
KD-A305J,KD-R300J,KD-R404UI
KD-R405U,KD-R405UN,KD-R405UT
KD-R405UH,KD-R406U,KD-R406UN
KD-R406UT,KD-R406UH, KD-S26J
COPYRIGHT 2009 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
KD-A305/KD-R300/KD-S26
