JVC KD-AR470 Service Manual

SCHEMATIC DIAGRAMS
CD RECEIVER
No.MA232SCH
2005/11
KD-AR470,KD-G420,KD-G521
KD-G524,KD-G525,KD-G527
COPYRIGHT 2005 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Area suffix
J ------------- Northern America
KD-AR470,KD-G420
Area suffix
E ------------- Southern Europe
EX ------------ Northern Europe
EY ------------- Eastern Europe
EU ------------------------- Turkey
KD-G521
Area suffix
UI ---------------------------- India
KD-G524
Area suffix
UT ------------------------- Taiwan
UH ---------------------- Thailand
UN --------------------- Indonesia
U -------------------- Other Areas
KD-G525
Area suffix
EE -------- Russian Federation
KD-G527
Contents
Block diagram (For KD-AR470,KD-G420,KD-G524 and KD-G525)
Standard schematic diagrams (For KD-AR470,KD-G420,KD-G524 and KD-G525)
Printed circuit boards (For KD-AR470,KD-G420,KD-G524 and KD-G525)
Block diagram (For KD-G521 and KD-G527)
Standard schematic diagrams (For KD-G521)
Standard schematic diagrams (For KD-G527)
Printed circuit boards (For KD-G521 and KD-G527)
2-1
2-3
2-9
2-13
2-15
2-21
2-27 to 29
CD-ROM No.SML200511
KD-AR470
KD-G527
KD-G420
KD-G521
KD-G524
KD-G525
