3-9
Main board (KD-G521)
Block No. [0][2]
R765 NRS181J-271X MG RESISTOR 270
Ω
1/8W J
R766 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R767 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
AR470J
G524UI
G525U
G525UH
G525UN
G525UT
R768 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
G420J
R771 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R772 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R775 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R776 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R780 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R781 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R784 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R785 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R787 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R791 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R792 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R793 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R801 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R802 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R803 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R804 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R805 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R806 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R807 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R808 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R809 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R810 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R851 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
G524UI
G525U
G525UH
G525UN
G525UT
R881 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R882 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R891 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
AR470J
R892 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
AR470J
R893 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
AR470J
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω
1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R904 NRSA02J-221X MG RESISTOR 220
Ω
1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R976 NRSA02J-203X MG RESISTOR 20k
Ω
1/10W J
R977 NRSA02J-822X MG RESISTOR 8.2k
Ω
1/10W J
RA30 NRZ0065-222X NET RESISTOR 2.2k
Ω
L1 QQL244J-4R7Z COIL 4.7uH J
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR1378-002 COIL
CN101 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0490-001 PIN JACK
AR470J
J321 QNN0489-001 PIN JACK
G420J
J321 QNN0519-001 PIN JACK
G524UI
G525U
G525UH
G525UN
G525UT
J801 QNZ0095-001 CONNECTOR
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSW1049-001Z TACT SW
TU1 QAU0312-002 TUNER PACK
X31 QAX0616-001Z CRYSTAL 10.250MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC71 SAA6579T-X IC
IC161 TDA7404D-E-X IC
IC301 TB2904HQ IC
IC401 TC94A34FG-002 IC
IC431 SN74AHCT1G04K-X IC
IC461 NJU7772F15-X IC
IC481 AK4385ET-X IC
IC501 LA6242H-X IC
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA IC
IC581 NJM4580M-X IC
IC701 UPD784217AGC347 IC
IC702 S-80833CNNB-G-W IC
IC771 BR24L32F-W-X IC
IC801 SN74AHC126NS-X IC
IC901 R2S25400DS-E REGULATOR IC
Q1 2SC3928A/QR/-X TRANSISTOR
Q2 2SC3928A/QR/-X TRANSISTOR
Q3 RT1P141C-X DIGI TRANSISTOR
Q5 2SA1530A/R/-X TRANSISTOR
Q6 2SA1365/F/-X TRANSISTOR
Q7 RT1N141C-X DIGI TRANSISTOR
Q10 RT1N141C-X DIGI TRANSISTOR
Q31 RT1N141C-X DIGI TRANSISTOR
Q51 2SC3928A/QR/-X TRANSISTOR
Q52 2SC3928A/QR/-X TRANSISTOR
Q53 RT1N141C-X DIGI TRANSISTOR
Q81 2SC3928A/QR/-X TRANSISTOR
Q84 RT1P141C-X DIGI TRANSISTOR
Q91 2SC3928A/QR/-X TRANSISTOR
Q241 2SC3928A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q440 RT1N141C-X DIGI TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q502 2SB1132/QR/-W TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q541 RT1P141C-X DIGI TRANSISTOR
Q542 RT1N141C-X DIGI TRANSISTOR
Q543 RT1P141C-X DIGI TRANSISTOR
Q544 2SA1365/F/-X TRANSISTOR
Q545 RT1N141C-X DIGI TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q782 KTD1304-X TRANSISTOR
Q784 RT1P141C-X DIGI TRANSISTOR
Q881 RT1N141C-X DIGI TRANSISTOR
Q891 RT1N141C-X DIGI TRANSISTOR
Q976 RT1N141C-X DIGI TRANSISTOR
Q977 2SA1530A/QR/-X TRANSISTOR
D1 1SS355W-X DIODE C.M
D2 1SS355W-X DIODE C.M
D4 1SS355W-X DIODE C.M
D5 1SS355W-X DIODE C.M
D84 1SS355W-X DIODE C.M
D242 1SS355W-X DIODE C.M
D243 CRS03-W SB DIODE
D244 UDZW5.1B-X SI DIODE
D341 1SS355W-X DIODE C.M
D351 1SS355W-X DIODE C.M
D481 UDZW5.1B-X SI DIODE
D701 UDZW6.2B-X SI DIODE
D702 UDZW6.2B-X SI DIODE
D703 UDZW6.2B-X SI DIODE
D704 UDZW6.2B-X SI DIODE
D705 UDZW6.2B-X SI DIODE
D706 UDZW6.2B-X SI DIODE
D707 UDZW6.2B-X SI DIODE
D708 UDZW6.2B-X SI DIODE
D709 UDZW6.2B-X SI DIODE
D710 UDZW5.6B-X Z DIODE
D711 UDZW5.6B-X Z DIODE
