JVC KD-AR470 Service Manual

3-17
Switch board
(KD-AR470/G420/G524/G525)
Block No. [0][4]
R743 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R744 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R745 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R746 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R747 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R748 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R749 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R750 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R751 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R752 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R753 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R754 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R755 NRSA63J-106X MG RESISTOR 10M Ω 1/16W J
R756 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R757 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R758 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R759 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R763 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R764 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R768 NRSA02J-271X MG RESISTOR 270 Ω 1/10W J
R771 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R772 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R774 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R775 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R776 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R777 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R781 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R782 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R783 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R793 NRS181J-0R0X MG RESISTOR 0 Ω 1/8W J
R801 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R802 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R803 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R804 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R805 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R806 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R807 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R808 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R810 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R881 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R882 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R891 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R892 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R901 QRE142J-102X C RESISTOR 1k Ω 1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k Ω 1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k Ω 1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k Ω 1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k Ω 1/8W J
R976 NRSA02J-273X MG RESISTOR 27k
Ω 1/10W J
R977 NRSA02J-123X MG RESISTOR 12k Ω 1/10W J
RA30 NRZ0065-222X NET RESISTOR 2.2k
Ω
RA550 NRZ0065-103X NET RESISTOR 10k Ω
RA701 NRZ0065-102X MG RESISTOR 1k Ω
L1 QQL244J-4R7Z COIL 4.7uH J
L401 NQL114K-470X INDUCTOR 47uH K
L402 NQL114K-470X INDUCTOR 47uH K
L404 NQL114K-470X INDUCTOR 47uH K
L541 QQL244J-470Z COIL 47uH J
L543 QQL244J-470Z COIL 47uH J
L544 QQL244J-470Z COIL 47uH J
L701 NQL114M-4R7X COIL 4.7uH M
L702 QQL244J-4R7Z COIL 4.7uH J
L710 NQR0007-002X FERRITE BEADS
L711 NQR0007-002X FERRITE BEADS
L712 NQR0007-002X FERRITE BEADS
L901 QQR1378-002 COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0859-001 CAR CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0519-001 PIN JACK
J801 QNZ0095-001 CONNECTOR
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSW1049-001Z TACT SW
 Symbol No. Part No. Part Name Description Local
 TU1 QAU0314-001 TUNER
X31 QAX0616-001Z CRYSTAL 10.250MHz
X71 QAX0263-001Z CRYSTAL 4.332MHz
X401 QAX0760-001Z CRYSTAL
X701 QAX0777-001Z CRYSTAL
X702 QAX0401-001 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q640 2SA1365/F/-X TRANSISTOR
Q641 RT1N141C-X DIGI TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MC2838-X DIODE
D641 UDZW5.1B-X SI DIODE
D642 1SS355W-X DIODE C.M
D643 UDZW6.2B-X SI DIODE
D645 NSPW310BS/B2RST LED
AR470J
G420J
D645 NSPW310BS/BRST/ WHITE LED
G521E
G521EU
G521EX
G521EY
G524UI
G525U
G525UH
G525UN
G525UT
G527EE
D646 NSPW310BS/B2RST LED
AR470J
G420J
D646 NSPW310BS/BRST/ WHITE LED
G521E
G521EU
G521EX
G521EY
G524UI
G525U
G525UH
G525UN
G525UT
G527EE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R606 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
