14
ENGLISH
Indications Selectable settings, [reference page]
SCROLL
*
1
Scroll
ONCE : [Initial]; Scrolls the disc information once.
AUTO : Repeats scrolling (5-second intervals in between).
OFF : Cancels.
• Pressing D DISP for more than one second can scroll the display
regardless of the setting.
EXT IN*
2
External input
CHANGER : [Initial]; To use a JVC CD changer, [9], an Apple iPod
or a JVC D. player, [16], a JVC compatible satellite
(SIRIUS/XM) tuner, [17].
EXT IN : To use any other component than the above, [16].
AUX ADJ
Auxiliary input level
adjustment
A.ADJ 00 – A.ADJ 05: Adjust the auxiliary input level accordingly,
to avoid the sudden increase of the output level when
changing the source from the external component
connected to the AUX input jack on the control panel.
[Initial: A.ADJ 00]
TAG DISP
Tag display
TAG ON : [Initial]; Shows the ID3 tag while playing MP3/WMA
tracks, [10].
TAG OFF : Cancels.
AMP GAIN
Amplifier gain control
You can change the maximum volume level of this unit.
LOW PWR : VOL 00 – VOL 30 (Select this if the maximum power
of the speaker is less than 50 W to prevent them from
damaging the speaker.)
HIGH PWR : [Initial]; VOL 00 – VOL 50
AREA
Tuner channel interval
AREA US : [Initial]; Select this when using the unit in North or
South America, except for Middle South America.
(FM: 200 kHz; AM: 10 kHz)
AREA EU : Select this when using the unit in any other area
than North, Middle South, and South America.
(FM: 50 kHz—manual tuning, 100 kHz—auto search;
AM: 9 kHz)
AREA SA : Select this when using the unit in Middle South
America. (FM: 100 kHz; AM: 10 kHz)
*
1
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*
2
Displayed only when one of the following sources is selected—FM, AM, CD, or AUX IN.
EN12-19KD-AR470_420[J]f.indd 14EN12-19KD-AR470_420[J]f.indd 14 10/4/05 2:53:08 PM10/4/05 2:53:08 PM
