Fader/Balance
Fader:
Adjust
the
front
and
rear
speaker
output
balance.
Balance:
Adjust
the
left
and
right
speaker
output
balance.
Volume
Adjust
*1
Subwoofer
Level
High
Pass
Filter
Crossover
Amplifier
Gain
*2
Rear
Speaker
*3
Dragging
also
makes
adjustments.
•
F06
to
R06;
Initial
00
(fader)
•
L06
to
R06;
Initial
00
(balance)
[.1
....
]:
Adjusts
fader.
[
"'/~]:
Adjusts
balance.
[
.$~
]:
Resets
the
adjustments.
•
When
using
a
two-speaker
system,
set
the
fader
to
the
center
(00).
Adjust
and
store
the
auto-adjustment
volume
level
for
each
source,
comparing
to
the
FM
volume
level.
The
volume
level
will
automatically
increase
or
decrease
when
you
change
the
source.
•
<Fix>
appears
when
an
FM
broadcast
is
selected
as
the
source.
• -12
to
+
12;
Initial
00
You
can
adjust
the
output
level
of
the
subwoofer
when
it
is
activated.(
~
'7)
• -06
to
+08;
Initial
00
•
Through
:
Select
when
the
subwoofer
is
not
connected.
•
On
:
Select
when
the
subwoofer
is
connected.
Select
the
crossover
frequency
between
the
frontlrear
speakers
and
the
subwoofer.
•
80Hz,
120Hz,
1
SOHz
You
can
change
the
maximum
volume
level
ofthis
unit.
•
Off
Deactivates
the
built-in
amplifier.
•
Low
Power
:
VOL
00
to
30
(Select
this
if
the
maximum
power
of
the
speakers
is
less
than
50
W.)
•
High
Power
:
VOL
00
to
50
You
can
activateldeactivate
the
rear
speakers
.
•
OO,On
*1
For
''DISC/USB'':
You
can
make
the
adjustments
separately
depending
on
the
audio
format-Dolby
digital
and
the
others.
*2
The
volume
level
automatically
changes
to
"30"
if
you
change
to
<Low
Power>
with
the
volume
level
set
higher
than
"30."
*3
This
setting
takes
effect
only
when
Dual
Zone
is
activated.
(~4
7)
24
