JVC KD-DB97BT

20
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
2-way crossover setting items
SPK SIZE
FRONT SIZE
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM /
4×6"
/ 5×7" / 6×8" / 6×9" / 7×10"
TWEETER
SML / MID / LRG / NONE (not connected)
REAR
*
1
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM / 4×6" / 5×7" /
6×8"
/ 6×9" / 7×10" / NONE (not connected)
SUBWOOFER
*
2
16CM / 20CM / 25CM / 30CM / 38CM OVER / NONE (not connected)
X ' OVER
TWEETER FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ /
8KHZ
/ 10KHZ / 12.5KHZ
GAIN LEFT
–08DB to 00DB
GAIN RIGHT
–08DB to 00DB
FRONT HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ
/ 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
SLOPE
–06DB / –12DB / –18DB / –24DB
GAIN
–08DB to 00DB
REAR HPF
*
1
FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ
/ 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
SLOPE
–06DB / –12DB / –18DB / –24DB
GAIN
–08DB to 00DB
SUB.W LPF
*
2
FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ
/ 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
SLOPE
–06DB / –12DB / –18DB / –24DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
3-way crossover setting items
SPK SIZE
TWEETER
SML/ MID/ LRG
MID RANGE
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM / 4×6" / 5×7" / 6×8" /
6×9"
WOOFER
*
2
16CM / 20CM / 25CM / 30CM / 38CM OVER / NONE (not connected)
X ' OVER
TWEETER HPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ
SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
MID RANGE HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
HPF SLOPE
–06DB / –12DB
LPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ / 12.5KHZ / THROUGH
LPF SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
WOOFER
*
2
LPF FRQ 30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ / 100HZ /
120HZ
/ 150HZ / 180HZ / 220HZ / 250HZ / THROUGH
SLOPE
–06DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –08DB to 00DB
*
1
Displayed only when [ SPK/PRE  OUT ] is set to [ REAR/REAR ]. (  19 )
*
2
Displayed only when [ SUB.W ] is set to [ ON ]. (  18 )
