JVC KD-DV6206 Installation & Connection Manual

4
ENGLISH
ˁ
A
Typical connections / նܔڅોሉ٘
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause
serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in
color.
1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.
*
2
Not supplied for this unit.
*
2
ʿᎲʹጅಏաé
Ignition switch
ᓭළᘕ
*
1
Only for KD-DV6206/KD-DV6205
*
1
ࡎ KD-DV6206/KD-DV6205
SUBWOOFER (see diagram / ኌ࿌ڷ )*
1
To external components
(see diagram )
в૊இά ኌ࿌ڷ 
Rear ground
terminal
ʹጅ݈ࠌ૊ϙၷʪ
15 A fuse
15 A ۘᎳീ
Black
෨и
To metallic body or chassis of the car
૊вہᚙᝂ׻ԆԾנᇟ
Yellow
*
3
෦и *
3
To a live terminal in the fuse block connecting to the car battery
(bypassing the ignition switch) (constant 12 V)
૊вۘᎳീవ˔˖ڄۈᚙၷʪçۘᎳീవ˔ؠԾ༫ྐЖߟ௤૊
·ؠཔᓭළᘕݔ׆12 V
Red
߹и
To an accessory terminal in the fuse block
૊вۘᎳീవ˔˖ڄۈᚙၷʪ
Blue
ᕇи
To the automatic antenna if any (250 mA max.)
૊вб˭ለࠜЉ༫௎ఛʨ250 mA
Blue with white stripe
ᕇиઘЉΎи଍ঙ
To the remote lead of other equipment (200 mA max.)
௤૊вմ༫໯ʕڄჲ૆዗ለఛʨ200 mA 
Orange with white stripe
ዻиઘЉΎи଍ঙ
To car light control switch
௤૊вԆԾԾጜ૆վළᘕ
To cellular phone system
૊в˾ጅԦ஀
Brown
ሶи
White with black stripe
ΎиઘЉ෨и଍ঙ
White
Ύи
Gray with black stripe
НиઘЉ෨и଍ঙ
Left speaker (front)
ಙᑵ዇ۮ໯
Gray
Ни
Green with black stripe
ႋиઘЉ෨и଍ঙ
Right speaker (front)
ಙᑵ዇ۮ໯
Green
ႋи
Purple with black stripe
ാиઘЉ෨и଍ঙ
Left speaker (rear)
ಙᑵ዇݈໯
Purple
ാи
Right speaker (rear)
ಙᑵ዇݈໯
Fuse block
ۘᎳീవ˔
Light green
ଠႋи
Line out (see diagram
)
᎔ၷʪ ኌ࿌ڷ 
VIDEO OUT (see diagram
/ ኌ࿌ڷ )
2nd AUDIO OUT (see diagram
/ ኌ࿌ڷ )*
1
LINE IN (see diagram / ኌ࿌ڷ )
To parking brake, metallic body or chassis of the car
૊в˾۫Ծ዗ለèہᚙᝂ׻ԆԾנᇟ
DIGITAL OUT
(see diagram
/ ኌ࿌ڷ )
ોሉۯ!அᐓފԆԾ˖ڄለཔéʿ͸ᇧڄ૊ለ๡዗ࠓʹጅᘷࡌ๑ᖢé
ྐʍለڄ˺ለ֜ԾԽڄ௤૊዇˺ለϚᖄиʕ঻Љ׿ʿψé
1 ՜ຖʓ࿌׿Ε˃ЎҺ௤૊ྐ຀ለڄᖄи዗ለé
2 અ˭ለڄྐለ௤૊৹գé
3 ఛ݈çӕለӧڄ಍Ꮓ಍Ϛʹጅʕé
*
3
Before checking the operation of this unit prior to
installation, this lead must be connected, otherwise
power cannot be turned on.
*
3
ʹጅ͵ϯ༫çනмʳѕٶٜᐓފ˃ۮç
 ෝӕ௠዗ለ૊ʕçѴ۱ʿ঻ළ૧ྐ຀é
Antenna connector
˭ለ௤૊዇
ELECTRICAL CONNECTIONS
ྑཕ௥ો
Instal4-6_DV6206_005A_1.indd 4Instal4-6_DV6206_005A_1.indd 4 2/27/06 1:24:16 PM2/27/06 1:24:16 PM
