JVC KD-G111

3-10
Main board(KD-G111_E2EX2EY2EU2)
Block No. [0][3]
 Symbol No. Part No. Part Name Description Local
IC161 TEA6320T-X IC
IC301 LA4743K POWER IC
IC501 TA2157FN-X RF AMP IC
IC521 TC94A14FA CD LSI IC
IC561 LA6242H-X IC
IC571 NJM4565M-WE IC
IC701 UPD178078GF-707 IC
IC901 HA13164A IC
Q1 UN2211-X TRANSISTOR
Q4 2SB709A/R/-X TRANSISTOR
Q5 2SB624/4/-X TRANSISTOR
Q6 UN2211-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q31 2SD601A/QR/-X TRANSISTOR
Q32 2SD601A/QR/-X TRANSISTOR
Q41 2SC3661-X TRANSISTOR
Q42 2SC3661-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q501 2SB1241/QR/-T TRANSISTOR
Q521 UN2111-X TRANSISTOR
Q522 UN2211-X TRANSISTOR
Q561 2SB1322/RS/-T TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2213-X DIGI TRANSISTOR
Q783 UN2111-X TRANSISTOR
Q901 2SB709A/QR/-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MA111-X SI DIODE
D4 MA111-X SI DIODE
D321 MA111-X SI DIODE
D341 MA111-X SI DIODE
D561 1A3G-T1 SI DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D783 MA8091/M/-X Z DIODE
D901 1N5401-F64 DIODE
D902 MA111-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
C2 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C3 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C6 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C8 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NDC31HJ-151X C CAPACITOR 150pF 50V J
C15 QEKJ1HM-224Z E CAPACITOR 0.22uF 50V M
C18 NDC31HJ-101X C CAPACITOR 100pF 50V J
C19 NDC31HJ-470X C CAPACITOR 47pF 50V J
C31 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C32 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C41 NCB31EK-563X C CAPACITOR 0.056uF 25V K
C42 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C43 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C55 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C81 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C82 NCB31HK-272X C CAPACITOR 2700pF 50V K
C91 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C92 NCB31HK-272X C CAPACITOR 2700pF 50V K
C162 NCB31HK-822X C CAPACITOR 8200pF 50V K
C163 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C164 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C165 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C166 NCB31HK-562X C CAPACITOR 5600pF 50V K
C167 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C168 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C172 NCB31HK-822X C CAPACITOR 8200pF 50V K
C173 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C174 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C175 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C176 NCB31HK-562X C CAPACITOR 5600pF 50V K
C177 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C178 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C182 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C183 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C185 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C186 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C191 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C192 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C193 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C194 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C195 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C196 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C301 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C302 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C303 QERF1CM-476Z E CAPACITOR 47uF 16V M
C304 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C305 QERF1CM-226Z E CAPACITOR 22uF 16V M
C306 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C308 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C309 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C310 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C311 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C312 NDC31HJ-101X C CAPACITOR 100pF 50V J
C313 NDC31HJ-101X C CAPACITOR 100pF 50V J
C314 NDC31HJ-101X C CAPACITOR 100pF 50V J
C315 NDC31HJ-101X C CAPACITOR 100pF 50V J
C316 NDC31HJ-101X C CAPACITOR 100pF 50V J
C317 NDC31HJ-101X C CAPACITOR 100pF 50V J
C318 NDC31HJ-101X C CAPACITOR 100pF 50V J
C319 NDC31HJ-101X C CAPACITOR 100pF 50V J
C321 NDC31HJ-101X C CAPACITOR 100pF 50V J
C322 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C331 NDC31HJ-101X C CAPACITOR 100pF 50V J
C332 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C333 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C341 NDC31HJ-101X C CAPACITOR 100pF 50V J
C342 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C351 NDC31HJ-101X C CAPACITOR 100pF 50V J
C352 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C504 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C505 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C507 NCB31HK-682X C CAPACITOR 6800pF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C509 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C510 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C511 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C512 NDC31HJ-820X C CAPACITOR 82pF 50V J
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C514 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C521 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C522 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C523 NDC31HJ-470X C CAPACITOR 47pF 50V J
C524 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C525 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C526 NCB31HK-272X C CAPACITOR 2700pF 50V K
C527 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C528 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C529 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C530 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C531 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C533 NDC31HJ-471X C CAPACITOR 470pF 50V J
C534 NDC31HJ-471X C CAPACITOR 470pF 50V J
C535 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C536 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C537 NCB31EK-473X C CAPACITOR 0.047uF 25V K
 Symbol No. Part No. Part Name Description Local
