DEMO Display demonstration
CLOCK H Hour adjustment
CLOCK M Minute adjustment
24H/12H 24/12-hour time display
AUTO ADJ Automatic clock setting
AF-REG Alternative frequency/
Regionalization reception
PTY STBY PTY standby
TA VOL Traffic announcement
volume
P-SEARCH Programme search
DIMMER Dimmer mode
TEL Telephone muting
SCROLL Scroll mode
TAG DISP Tag display
AMP GAIN Amplifier gain control
Preferred Setting Mode (PSM) items
• For detailed operations of each PSM items, refer to the pages listed in the table.
Indications Selectable values/items
Factory-preset See
settings page
DEMO ONDEMO OFF DEMO ON 6
00 (0:00)
OFFOFF ON 32
LOW PWR HIGH PWR HIGH PWR 32
12H 24H
OFF ON
24H
ON 17
AF
AF AF REG
OFF
12, 13
VOL 00 — VOL 30 or 50* VOL 20
OFF ON OFF
17
17
OFF
OFF
29 programme types
(see page 18)
14
* Depending on the amplifier gain control setting. (See page 32 for details.)
OFF
MUTING 2
MUTING 1
OFF
32
ONCE
ONCE AUTO
OFF
32
TAG OFF TAG ON TAG ON 32
EN30-33_KD-G401[E_EX_EU]f.p65 7/11/03, 7:11 PM31

JVC KD-G401 Specifications

Audio Amplifier

maximum power output (front)	50 W per channel
maximum power output (rear)	50 W per channel
continuous power output (RMS) (front)	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output (RMS) (rear)	19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance	4 Ω (4 Ω to 8 Ω allowance)
tone control range (bass)	±10 dB at 100 Hz
tone control range (treble)	±10 dB at 10 kHz
frequency response	40 Hz to 20 000 Hz
signal-to-noise ratio	70 dB
line-out level/impedance	2.0 V/20 kΩ load (full scale)
output impedance	1 kΩ

CD Player

operating voltage	DC 14.4 V (11 V to 16 V allowance)
allowable operating temperature	0°C to +40°C
dimensions (W × H × D)	182 mm × 52 mm × 150 mm
panel size	188 mm × 58 mm × 11 mm
mass	1.3 kg (excluding accessories)
frequency response	5 Hz to 20 000 Hz
dynamic range	96 dB
signal-to-noise ratio	98 dB
max. bit rate	320 Kbps

Tuner

frequency range (FM)	87.5 MHz to 108.0 MHz
frequency range (AM MW)	522 kHz to 1 620 kHz
frequency range (AM LW)	144 kHz to 279 kHz
usable sensitivity	11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity	16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz)	65 dB
frequency response	40 Hz to 15 000 Hz
stereo separation	30 dB
capture ratio	1.5 dB
sensitivity (MW)	20 µV
selectivity (MW)	35 dB
sensitivity (LW)	50 µV
