JVC KD-G541 - Technical Specifications; Audio Amplifier Specifications; Tuner Section Specifications

34
ENGLISH
Specifications
AUDIO AMPLIFIER SECTION
Maximum Power Output: Front and Rear: 50 W per channel
Continuous Power Output (RMS): Front and Rear: 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more
than 0.8% total harmonic distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range: Bass: ±12 dB at 60 Hz
Middle: ±12 dB at 1 kHz
Treble: ±12 dB at 7.5 kHz
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance: 2.5 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
Subwoofer-Out Level/Impedance: 2.5 V/20 kΩ load (full scale)
Other Terminal: CD changer jack, AUX (auxiliary) input jack, Steering
wheel remote input
TUNER SECTION
Frequency Range: FM: 87.5 MHz to 108.0 MHz
AM: (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
FM Tuner: Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting
Sensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel
Selectivity
(400 kHz):
65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
MW Tuner: Sensitivity/
Selectivity:
20 μV/35 dB
LW Tuner: Sensitivity: 50 μV
