(No.MA147)1-15
3.2.5
Removing the c
lamper assembly
(See Figs.10 and 11)
•
Prior to performing
the following procedure
, remove the top
cover.
(1)
Remove the clamper arm spring.
(2)
Move the clamper assembl
y in the direction of the arrow to
release the two joints
d
.
Fig.10
Fig.11
Clamper arm
spring
Chassis rivet
assembly
Joint d
Joint d
Clamper assembly
Clamper arm spring
Clamper assembly
Joint d
Joint d
Chassis rivet assembly
14
16
Table of Contents
