JVC KD-G615 Service Manual

3-10
Switch board (KD-G615_UT,UH,UN,U)
Block No. [0][2]
Mechanism control board
(KD-G615_UT,UH,UN,U)
Block No. [0][3]
 Symbol No. Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q640 2SB624/4/-X TRANSISTOR
Q641 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 CL-190UB2-X-X LED
D609 CL-190UB2-X-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MA152WK-X SI DIODE
D641 UDZS5.1B-X Z DIODE
D642 MA111-X SI DIODE
D643 MA8062/M/-X Z DIODE
D645 NSPW310BS/BRS/ LED
G615
UN
D645 NSPW310BS/BRST/ WHITE LED
G615
U,G61
5UH,
G615
UT
D646 NSPW310BS/BRS/ LED
G615
UN
D646 NSPW310BS/BRST/ WHITE LED
G615
U,G61
5UH,
G615
UT
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R606 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R611 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R612 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R614 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R630 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R632 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R634 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R636 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R638 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R640 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R641 NRSA02J-181X MG RESISTOR 180
Ω 1/10W J
R642 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R643 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R644 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R646 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R648 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R660 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R661 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R672 NRSA02J-471X MG RESISTOR 470
Ω 1/10W J
R673 NRSA02J-473X MG RESISTOR 47k
Ω 1/10W J
R674 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R691 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R692 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER
J601 QNS0245-001 AUX JACK
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
 Symbol No. Part No. Part Name Description Local
IC501 TMP91CW12AF5VD9 IC
IC502 BR24L01AFV-W-X IC
IC503 SN74AHCT126PW-X IC(DIGITAL)
IC504 NJU7241F33-X IC
IC571 PCM1753-X IC
IC572 NJM4580V-X IC
IC573 SN74AHCU04PW-X IC
IC601 TA2157FN-X RF AMP IC
IC621 TC94A14FA CD LSI IC
IC651 NJU7772F15-X IC
IC652 TC94A34FG-002 IC
IC681 BA5830FP-X IC
Q501 UN2111-X TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q571 UN2111-X TRANSISTOR
Q572 UN2211-X TRANSISTOR
Q573 2SB624/4/-X TRANSISTOR
Q574 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q651 2SB624/4/-X TRANSISTOR
Q652 UN2211-X TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D506 MA111-X SI DIODE
D682 1SR154-400-X DIODE
 Symbol No. Part No. Part Name Description Local
