3-12
Main board (KD-G615_UH2,UN2,U2)
Block No. [0][4]
R554 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R555 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R556 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R557 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R558 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R559 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R560 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R561 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R562 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R563 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R568 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R569 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R570 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R572 NRSA63J-225X MG RESISTOR 2.2M
Ω
1/16W J
R573 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R574 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R575 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R576 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R577 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R578 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R579 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R581 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R582 NRSA63J-243X MG RESISTOR 24k
Ω
1/16W J
R583 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R584 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R585 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R586 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R587 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R588 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R589 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R590 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R591 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R592 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R593 NRSA63J-4R7X MG RESISTOR 4.7
Ω
1/16W J
R594 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R595 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R601 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R602 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R603 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R604 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R605 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R606 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R607 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R608 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R609 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R610 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R611 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R612 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
R613 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R614 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R615 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R616 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R621 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R622 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R623 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R624 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R625 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R626 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R627 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R628 NRSA63J-155X MG RESISTOR 1.5M
Ω
1/16W J
R629 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R630 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R631 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R632 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R633 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R634 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R635 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R636 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R637 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R638 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R639 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R640 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R641 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R642 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R651 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R654 NRSA63J-390X MG RESISTOR 39
Ω
1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R656 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R657 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R668 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R675 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R681 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R682 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R683 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R684 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R685 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R686 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R687 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R688 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R689 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R690 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R691 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
L501 NQL114K-470X INDUCITOR 47uH K
L502 NQL114K-470X INDUCITOR 47uH K
L572 NQL114K-470X INDUCITOR 47uH K
L621 NQL114K-470X INDUCITOR 47uH K
L622 NQL114K-470X INDUCITOR 47uH K
L623 NQL114K-470X INDUCITOR 47uH K
L651 NQL114K-470X INDUCITOR 47uH K
L652 NQL114K-470X INDUCITOR 47uH K
L653 NQL114K-470X INDUCITOR 47uH K
CN501 QGB2027L1-22X CONNECTOR B-B (1-22)
CN601 QGF0527F2-22W CONNECTOR FFC/FPC (1-22)
TH501 NAD0028-103X N THERMISTOR 10k
Ω
X501 NAX0385-001X CRYSTAL 24.576MHz
X571 NAX0375-001X CRYSTAL 16.9344MHz
Symbol No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC161 TDA7404D-E-X IC
IC251 NJM4565M-WE IC
IC271 CD4066BPW-X IC
IC301 TB2906HQ IC
IC701 UPD784217AGC322 IC
IC702 IC-PST3433U-X IC
IC771 BR24L16F-W-X IC
IC801 HD74HC126FP-X IC
IC901 HA13164A IC
Q1 KTD1304-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q8 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q241 2SD601A/R/-X TRANSISTOR
Q271 KTD1304-X TRANSISTOR
Q272 UN2111-X TRANSISTOR
Q273 UN2211-X TRANSISTOR
Q274 UN2211-X TRANSISTOR
Q321 KTD1304-X TRANSISTOR
Q331 KTD1304-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q701 UN2211-X TRANSISTOR
Q702 UN2211-X TRANSISTOR
Q703 UN2211-X TRANSISTOR
Q704 UN2211-X TRANSISTOR
Q705 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 KTD1304-X TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q881 UN2211-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q901 2SB1132/QR/-W TRANSISTOR
Q976 UN2211-X TRANSISTOR
Symbol No.
Part No. Part Name Description Local
