JVC KD-G615 Service Manual

3-18
R610 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R611 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R612 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
R613 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R614 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R615 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R616 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R621 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R622 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R623 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R624 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R625 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R626 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R627 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R628 NRSA63J-155X MG RESISTOR 1.5M
Ω 1/16W J
R629 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R630 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R631 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R632 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R633 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R634 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R635 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R636 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R637 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R638 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R639 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R640 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R641 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R642 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R651 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R654 NRSA63J-390X MG RESISTOR 39
Ω 1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R656 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R657 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R668 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R675 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R681 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R682 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R683 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R684 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R685 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R686 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R687 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R688 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R689 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R690 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R691 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
L501 NQL114K-470X INDUCITOR 47uH K
L502 NQL114K-470X INDUCITOR 47uH K
L572 NQL114K-470X INDUCITOR 47uH K
L621 NQL114K-470X INDUCITOR 47uH K
L622 NQL114K-470X INDUCITOR 47uH K
L623 NQL114K-470X INDUCITOR 47uH K
L651 NQL114K-470X INDUCITOR 47uH K
L652 NQL114K-470X INDUCITOR 47uH K
L653 NQL114K-470X INDUCITOR 47uH K
CN501 QGB2027L1-22X CONNECTOR B-B (1-22)
CN601 QGF0527F2-22W CONNECTOR FFC/FPC (1-22)
TH501 NAD0028-103X N THERMISTOR 10k
Ω
X501 NAX0385-001X CRYSTAL 24.576MHz
X571 NAX0375-001X CRYSTAL 16.9344MHz
 Symbol No. Part No. Part Name Description Local
