ENGLISH
31
AUDIO AMPLIFIER SECTION
Power Output:
20 W RMS × 4 Channels
at 4 Ω and ≤ 1% THD+N
Signal to Noise Ratio:
80 dBA
(reference: 1 W into 4 Ω)
SRS Circle Surround Auto
TM
Compatible
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Equalizer Control Range:
60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz,
6 kHz, 15 kHz
Level:±10 dB
Frequency Response: 40 Hz to 20 000 Hz
Line-Out Level/Impedance:
2.5 V /20 kΩ load (full scale)
Output Impedance: 1 kΩ
Subwoofer-Out Level/Impedance:
2.0 V /20 kΩ load (full scale)
Other Terminal: CD changer
TUNER SECTION
HD Radio System Compatible
Frequency Range:
FM: 87.5 MHz to 107.9 MHz
(with channel interval set to 100 kHz
or 200 kHz)
87.5 MHz to 108.0 MHz
(with channel interval set to 50 kHz)
AM: 530 kHz to 1 710 kHz
(with channel interval set to 10 kHz)
531 kHz to 1 602 kHz
(with channel interval set to 9 kHz)
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting Sensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response:
HD Radio broadcast: 20 Hz to 20 000 Hz
Conventional broadcast: 40 Hz to 15 000 Hz
Stereo Separation:
HD Radio broadcast: 85 dB
Conventional broadcast: 35 dB
Capture Ratio: 1.5 dB
Specifications
[AM Tuner]
Sensitivity: 20 μV
Selectivity: 35 dB
Frequency Response: 30 Hz to 15 000 Hz
(HD Radio broadcast)
Stereo Separation: 85 dB (HD Radio broadcast)
CD PLAYER SECTION
Type: Compact disc player
Signal Detection System: Non-contact optical
pickup (semiconductor laser)
Number of Channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 98 dB
Signal-to-Noise Ratio: 102 dB
Wow and Flutter: Less than measurable limit
MP3 Decoding Format:
MPEG1/2 Audio Layer 3
Max. Bit Rate: 320 kbps
WMA (Windows Media
®
Audio) Decoding
Format:
Max. Bit Rate: 192 kbps
GENERAL
Power Requirement:
Operating Voltage:
DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature:
0°C to +40°C (32°F to 104°F)
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 150 mm
(7-3/16
" × 2-1/16" × 5-15/16")
Panel Size (approx.):
188 mm × 58 mm × 11 mm
(7-7/16
" × 2-5/16" × 7/16")
Mass (approx.):
1.5 kg (3.3 lbs) (excluding accessories)
Design and specifications are subject to change
without notice.
If a kit is necessary for your car, consult your
telephone directory for the nearest car audio
speciality shop.
