JVC KD-HDR71BT Instruction Manual

You can select your preferred brightness for <BUTTON ZONE>, <DISP ZONE> separately.
(Hold)
1
-<DIMMER>
-<BRIGHTNESS>
-<DAY>/<NIGHT>
2
BUTTON ZONE BUTTON 00 to 31
DISP ZONE DISP 00 to 31
3
4
Press MENU to exit.
Sound adjustments
This unit memorizes sound settings adjusted for each individual source.
Satellite Radio tuner and EXT IN share the same sound adjustment settings.
Selecting the preset sound
You can select a preset sound mode, for each
individual source, suitable for the music genre.
1
(Hold)
-<EQ SETTING>
-<EQ PRESET>
2
3
DYNAMIC-VOCAL BOOST-BASS BOOST-
USER-FLAT-NATURAL-(back to the beginning)
Storing your own adjustments
While listening, you can adjust and store the tone
level for each individual source.
Easy Equalizer
(Hold)
1
-<EQ SETTING>
-<EASY EQ>
2
(Initial: [XX])
SUB.W * 00 to 08 [08]
BASS LVL ** -06 to +06 [+05]
MID LVL -06 to +06 [00]
TRE LVL -06 to +06 [+05]
The adjustments are stored and <USER> is
activated.
3
Adjust the level.
Pro Equalizer
(Hold)
1
-<PRO EQ>
-<BASS>**/<MIDDLE>/
<TREBLE>
2
Adjust the sound elements of the selected tone.
BASS (Initial: [XX])
Frequency 60/80/[100]/200 Hz
Level LVL -06 to +06 [+05]
Q [Q1.0]/Q1.25/Q1.5/Q2.0
MIDDLE
Frequency 0.5/[1.0]/1.5/2.5 kHz
Level LVL -06 to +06 [00]
Q Q0.75/Q1.0/[Q1.25]
TREBLE
Frequency 10.0/[12.5]/15.0/17.5 kHz
Level LVL -06 to +06 [+05]
Q [Q FIX]
3
4
Repeat steps 2 and 3 to adjust other tones.
The adjustments are stored and <USER> is
activated.
5
Press MENU to exit.
* Available only when <SUB.W> is set to
<ON>. (' page 24)
** Available only when <HPF> is set to <OFF>.
(' page 24) (KD-HDR71BT only)
Brightness adjustments
Brightness adjustments
22
|ޓENGLISH
2011/12/17ޓ14:6:9KD-AHD75_J_EN
