1-11
KD-LH7R
Prior to performing the following procedure, remove
the top cover, the connector board and the chassis
unit.
Remove the screw C and move the loading / feed
motor assembly in the direction of the arrow to
remove it from the chassis rivet assembly.
Disconnect the wire from the loading / feed motor
assembly if necessary.
1.
2.
Removing the loading / feed motor
assembly (See Fig.11 and 12)
Prior to performing the following procedure, remove
the top cover.
Remove the clamper arm spring.
Move the clamper assembly in the direction of the
arrow to release the two joints d.
1.
2.
Removing the clamper assembly
(See Fig.9 and 10)
When reassembling, connect the wire
from the loading / feed motor assembly
to the flame as shown in Fig.11.
CAUTION:
Fig.9
Fig.10
Fig.12Fig.11
Clamper arm
spring
Clamper arm spring
Chassis rivet
assembly
Joint d
Joint d
Clamper assembly
Clamper assembly
Joint d
Joint d
Chassis rivet assembly
Loading / feed motor assembly
Loading / feed motor assembly
C
