1-7
KD-LH7R
Prior to performing the following procedure, remove
the top cover.
Disconnect the wire from connector CN601 on the
MP3 board.
Remove the five screws G and the MP3 board,
releasing the joint g and h.
1.
2.
Removing the MP3 board
(See Fig.9)
Prior to performing the following procedure, remove
the front chassis, the heat sink, bottom cover and the
main amplifier board assembly.
Remove the three screws H attaching the cassette
mechanism assembly from the top cover.
1.
Removing the CD mechanism assembly
(See Fig.10)
Fig.9
G
g
h
CN601
G
CD mechanism assembly
H
H
Top cover
Fig. 10
H
