ENGLISH
Control panel — KD-LH911
Parts identification
1 + / – button
2 (standby/on attenuator) button
3 5 (up) button
4
4/¢ buttons
5 Display window
6 T/P (traffic programme/programme type)
button
7 0 (eject) button
(angle) button
8 SOURCE button
9 OK button
p Reset button
q ∞ (down) button
w Remote sensor
• DO NOT expose the remote sensor to
strong light (direct sunlight or artificial
lighting).
e MENU button
r DISP (display) button
t BACK button
y
(control panel release) button
u BAND button
