JVC KD-LX50R Service Manual

Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M3MM
62 19501403T WIRE CLAMPER 3
63 30311037T PICK UP FPC
(
Z
)
1
64 30311036T CONNECT.PCB
(
Z-J 1
65 30311038T WIRE
(
5P-Z
)
1
66 30311039T WIRE
(
LD-Z
)
1
67 30311040T WIRE
(
FD-Z
)
1
68 30311041T WIRE
(
RS-Z
)
1
70 64180402T DET SWITCH 2 ESE22MH1
71 64180403T DET SWITCH 2 ESE22MH3
72 68150232T CONNECTOR 1 TKC-W26X-C1
78 --------- LDG PULLEY 1
79 30311105T SOPPORT PLATE 1
80 30311138T GR MT BLK
(
N
)
1
81 30311109T LDG GEAR
(
2
)
1
82 30311110T LDG GEAR
(
3
)
1
83 --------- LDG GEAR
(
4
)
1
84 30311112T LDG GEAR
(
5
)
1
85 --------- LDG GR ARM 1
86 30311136T LDG ROLLER 2
87 --------- LDG RLR SHAFT 1
88 30311118T L.P SPRING
(
L
)
1
89 30311119T L.P SPRING
(
R
)
1
90 30311123T SW PCB 1
91 30311124T SW ACTUATOR 1
92 30311129T LDG BELT 1
93 30311140T FRONT BRKT
(
J
)
1
100 9C0620503T C B TAP SCREW 2 M2X5
101 9C2020401T C SCREW TS.G 5 M2X4
102 9C4320403T C B TAP SCREW 4 M2X4
103 9C0117223T SCREW 2 M1.7X2.2
104 9C4217703T C TAP SCREW S3 1 M1.7X7
105 9C0320201T C TAP SCREW S3 1 M2X2
106 9C4920013T C TAP SCREW S3 2 M2X10
107 9C4920603T C TAP SCREW B3 4 M2X6
108 9P0220031T TAMS SCREW 2 M2X3
110 9C0420253 C TAP SCREW 1 M2X2.5
112 --------- POLY WASHER 1 2.1X3.5X0.3
113 9W0330276 NW BLUE 2 2.9X5X0.3
114 ---------- WAVE WASHER 1
115 ---------- LUMILAR WASHER 1 2.5X6X0.1
116 9W0735080T LUMILAR W 1 2.3X9.8X0.35
117 9W0640030T WASHER 1 1.4X3.2X0.4
130 303105310T FEED MO ASSY 1 NO.34 54
131 303105311T SPINDLE MO ASSY 1 NO.31 55 112
132 303105312T FEED SCREW ASSY 1 NO.35 37
133 303111301T LDG MOTOR ASSY 1 NO.54 78
134 303111302T RDG RLR SFT ASY 1 NO.114 115
303111302T RDG RLR SFT ASY 1 NO.83 85 87
(CD mechanism)
135 303105502T T.T.BASE ASSY 1 NO.30 46 47
