Item

Parts number Parts name Area

Electrical parts list

Remarks

Block No. 01

C 1 NCB21EK-473X C CAPACITOR

C 2 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 3 NCB21HK-103X C CAPACITOR

C 4 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 5 QER41AM-227 E CAPACITOR 220MF 20% 10V

C 6 NCB21EK-473X C CAPACITOR

C 7 NCB21HK-183X C CAPACITOR

C 8 NCB21HK-104X C CAPACITOR

C 10 NCS21HJ-101X C CAPACITOR

C 11 NCB21HK-473X C CAPACITOR

C 21 NCS21HJ-331X C CAPACITOR

C 22 NCB21HK-103X C CAPACITOR

C 23 NCB21HK-472X C CAPACITOR

C 24 NCB21EK-104X C CAPACITOR

C 25 QERF1HM-474Z E CAPACITOR .47MF 20% 50V

C 31 NCB21HK-103X C CAPACITOR

C 32 QEK41HM-474 E CAPACITOR .47MF 20% 50V

C 33 NCB21HK-102X C CAPACITOR

C 34 NCB21HK-682X C CAPACITOR

C 35 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 36 NCB21HK-152X C CAPACITOR

C 37 NCB21HK-103X C CAPACITOR

C 38 NCB21EK-473X C CAPACITOR

C 39 QEKJ1HM-104Z E CAPACITOR .10MF 20% 50V

C 40 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 41 NCB21HK-103X C CAPACITOR

C 42 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 43 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 44 QER41HM-105 E CAPACITOR 1.0MF 20% 50V

C 45 QER41HM-105 E CAPACITOR 1.0MF 20% 50V

C 46 NBE21CM-105X C CAPACITORM

C 51 NDC21HJ-820X C CAPACITOR

C 52 NDC21HJ-470X C CAPACITOR

C 53 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 54 NCB21HK-103X C CAPACITOR

C 55 NCS21HJ-561X C CAPACITOR

C 56 NCB21EK-223X C CAPACITOR

C 57 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 101 NCB21HK-153X C CAPACITOR

C 102 NCS21HJ-681X C CAPACITOR

C 103 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V

C 112 NBE21AM-475X TS E CAPACITOR

C 117 NCB21HK-104X C CAPACITOR

C 118 NCB21HK-472X C CAPACITOR

C 119 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 120 NCB21HK-471X C CAPACITOR

C 141 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 142 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 143 NCS21HJ-331X C CAPACITOR

C 144 NCS21HJ-331X C CAPACITOR

C 151 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V

C 152 NCS21HJ-821X C CAPACITOR

C 153 NCS21HJ-121X C CAPACITOR

C 155 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 156 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 161 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 162 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 163 NCB21EK-473X C CAPACITOR

C 164 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V

C 172 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 173 QERF0JM-226Z E CAPACITOR 22MF 20% 6.3V

C 174 NCB21EK-223X C CAPACITOR

C 175 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 201 NCB21HK-153X C CAPACITOR

C 202 NCS21HJ-681X C CAPACITOR

C 203 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V

C 212 NBE21AM-475X TS E CAPACITOR

C 218 NCB21HK-472X C CAPACITOR

C 219 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 220 NCB21HK-471X C CAPACITOR

C 241 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 242 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 243 NCS21HJ-331X C CAPACITOR

C 244 NCS21HJ-331X C CAPACITOR

C 251 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V

C 252 NCS21HJ-821X C CAPACITOR

C 253 NCS21HJ-121X C CAPACITOR

C 272 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 273 QERF0JM-226Z E CAPACITOR 22MF 20% 6.3V

C 301 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 302 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 303 QEK41CM-476 E CAPACITOR 47MF 20% 16V

C 305 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 306 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 307 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 308 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 309 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 310 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 321 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 322 NCB21HK-103X C CAPACITOR

C 323 QEK41CM-476 E CAPACITOR 47MF 20% 16V

C 324 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 325 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 327 NCB21EK-823X C CAPACITOR

C 328 NCB21HK-682X C CAPACITOR

C 329 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 330 NCB21HK-123X C CAPACITOR

C 331 NCB21HK-562X C CAPACITOR

C 332 NCB21HK-273X C CAPACITOR

C 333 NCB21HK-273X C CAPACITOR

C 334 NCB21HK-333X C CAPACITOR

C 335 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 336 NCB21HK-473X C CAPACITOR

C 337 NCB21HK-473X C CAPACITOR

C 351 NCB21HK-104X C CAPACITOR

C 352 NCB21HK-103X C CAPACITOR

C 353 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 354 NCB21HK-104X C CAPACITOR

C 355 NCB21HK-471X C CAPACITOR

C 356 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 357 NCB21HK-472X C CAPACITOR

C 358 NCB21CK-224X C CAPACITOR

C 359 NCB21CK-224X C CAPACITOR

C 401 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 402 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 403 QEK41CM-476 E CAPACITOR 47MF 20% 16V

C 405 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 406 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 407 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 408 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 409 QEK41EM-475 E CAPACITOR 4.7MF 20% 25V

C 410 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 451 NCB21HK-104X C CAPACITOR

C 452 NCB21HK-103X C CAPACITOR

C 454 NCB21HK-104X C CAPACITOR

C 455 NCB21HK-471X C CAPACITOR

C 456 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 457 NCB21HK-472X C CAPACITOR

(Main board)

Item

Parts number Parts name Area

Remarks

Brand	JVC
Model	KD-LX50R
Category	Car Receiver
Language	English

JVC KD-LX50R Service Manual
