Item

Parts number Parts name Area

Electrical parts list

Remarks

Block No. 01

C 458 NCB21CK-224X C CAPACITOR

C 459 NCB21CK-224X C CAPACITOR

C 501 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 502 NCB21HK-103X C CAPACITOR

C 503 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 504 NCB21HK-103X C CAPACITOR

C 505 NCB21HK-103X C CAPACITOR

C 506 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 507 NCB21HK-103X C CAPACITOR

C 508 NCB21EK-104X C CAPACITOR

C 509 NCB21EK-104X C CAPACITOR

C 510 NDC21HJ-560X C CAPACITOR

C 512 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 513 NCB21HK-103X C CAPACITOR

C 514 NCS21HJ-101X C CAPACITOR

C 521 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 522 NCB21HK-103X C CAPACITOR

C 523 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 525 NCB21HK-103X C CAPACITOR

C 526 NCB21HK-103X C CAPACITOR

C 531 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 532 NCB21HK-103X C CAPACITOR

C 533 NCS21HJ-470X C CAPACITOR

C 534 NCB21HK-153X C CAPACITOR

C 535 NCB21HK-103X C CAPACITOR

C 536 NCB21HK-103X C CAPACITOR

C 537 NCB21HK-272X C CAPACITOR

C 538 NCB21HK-103X C CAPACITOR

C 539 NCB21HK-333X C CAPACITOR

C 542 NCB21HK-182X C CAPACITOR

C 543 NCS21HJ-271X C CAPACITOR

C 545 NCB21EK-473X C CAPACITOR

C 546 NCB21EK-473X C CAPACITOR

C 547 NCB21EK-473X C CAPACITOR

C 549 NCB21EK-473X C CAPACITOR

C 550 NCB21EK-104X C CAPACITOR

C 551 QER41CM-106 E CAPACITOR 10MF 20% 16V

C 552 NCB21HK-103X C CAPACITOR

C 553 NCB21HK-103X C CAPACITOR

C 554 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 555 NCB21HK-103X C CAPACITOR

C 556 NDC21HJ-100X C CAPACITOR

C 557 NDC21HJ-100X C CAPACITOR

C 558 NCS21HJ-101X C CAPACITOR

C 571 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 573 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 574 NCB21HK-103X C CAPACITOR

C 581 QEKJ1CM-107Z E CAPACITOR 100MF 20% 16V

C 582 NCB21HK-103X C CAPACITOR

C 583 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 584 NCB21HK-473X C CAPACITOR

C 701 NDC21HJ-220X C CAPACITOR

C 702 NDC21HJ-270X C CAPACITOR

C 703 NDC21HJ-270X C CAPACITOR

C 704 NDC21HJ-8R0X C CAPACITOR

C 705 NCS21HJ-471X C CAPACITOR

C 707 NCB21EK-103X C CAPACITOR

C 708 NBE21AM-106X E CAPACITOR

C 710 QER41AM-227 E CAPACITOR 220MF 20% 10V

C 711 NCS21HJ-471X C CAPACITOR

C 713 QER41AM-227 E CAPACITOR 220MF 20% 10V

C 719 NCS21HJ-471X C CAPACITOR

C 722 NCB21HK-222X C CAPACITOR

C 723 NCB21HK-222X C CAPACITOR

C 724 NCB21HK-222X C CAPACITOR

C 754 NCB21EK-104X C CAPACITOR

C 771 NCB21EK-473X C CAPACITOR

C 791 QERF1HM-104Z E CAPACITOR .10MF 20% 50V

C 821 NCB21HK-183X C CAPACITOR

C 822 NCB21EK-393X C CAPACITOR

C 823 NCB21EK-393X C CAPACITOR

C 824 NCB21EK-393X C CAPACITOR

C 825 NCB21EK-393X C CAPACITOR

C 826 NCB21HK-122X C CAPACITOR

C 827 QER41CM-106 E CAPACITOR 10MF 20% 16V

C 828 QER41CM-106 E CAPACITOR 10MF 20% 16V

C 911 QEK41CM-476 E CAPACITOR 47MF 20% 16V

C 912 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 913 NCB21EK-104X C CAPACITOR

C 914 NCB21EK-473X C CAPACITOR

C 921 NCS21HJ-101X C CAPACITOR

C 922 NCS21HJ-101X C CAPACITOR

C 923 NCS21HJ-101X C CAPACITOR

C 924 NCS21HJ-101X C CAPACITOR

C 925 NCS21HJ-101X C CAPACITOR

C 926 NCS21HJ-101X C CAPACITOR

C 927 NCS21HJ-101X C CAPACITOR

C 928 NCS21HJ-101X C CAPACITOR

C 931 NDC21HJ-101X C CAPACITOR

C 932 NCB21EK-473X C CAPACITOR

C 941 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 942 QEK41CM-476 E CAPACITOR 47MF 20% 16V

C 943 NCB21HK-103X C CAPACITOR

C 944 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 946 NCB21EK-104X C CAPACITOR

C 947 NCB21EK-104X C CAPACITOR

C 948 NCB21EK-104X C CAPACITOR

C 949 NCB21EK-104X C CAPACITOR

C 951 NCB21HK-104X C CAPACITOR

C 952 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 961 QEZ0337-228 E CAPACITOR 2200MF

C 962 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 964 QER41AM-227 E CAPACITOR 220MF 20% 10V

C 965 QER41AM-227 E CAPACITOR 220MF 20% 10V

C 966 NCB21HK-103X C CAPACITOR

C 967 QERF1CM-226Z E CAPACITOR 22MF 20% 16V

C 968 NCB21EK-104X C CAPACITOR

C 969 QER41CM-106 E CAPACITOR 10MF 20% 16V

C 971 QERF1CM-226Z E CAPACITOR 22MF 20% 16V

C 977 QEK41CM-476 E CAPACITOR 47MF 20% 16V

C 978 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 982 QEK41CM-106 E CAPACITOR 10MF 20% 16V

C 986 NCB21EK-104X C CAPACITOR

CF 31 QAX0605-001 CRYSTAL

CN301 QGA2501C1-07 7P CONNECTOR

CN302 QGA2501C1-06 6P CONNECTOR

CN501 QGB2027M2-26X CONNECTOR

CN503 QGA2501F1-02 CONNECTOR

CN504 QGA2501F1-02 CONNECTOR

CN701 QGF0503C1-16V FPC CONNE

CN702 QGF0501F1-06X CONNECTOR C.M

CN704 QGA1201C2-04X CONNECTOR

CN705 QGA2006C1-02 CONNECTOR

CN771 QNZ0095-001 CONNECTOR

CN901 QNZ0090-001 CAR CONNECTOR

D 1 1SS355-X DIODE

D 2 1SS355-X DIODE

D 3 1SS355-X DIODE

(Main board)

Item

Parts number Parts name Area

Remarks
