JVC KD-LX50R Service Manual

Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
D 11 MA152WK-X SI DIODE
D 31 1SS355-X DIODE
D 101 MA152WK-X SI DIODE
D 111 MA152WK-X SI DIODE
D 131 MA152WA-X DIODE
D 161 1SS355-X DIODE
D 162 1SS355-X DIODE
D 201 MA152WK-X SI DIODE
D 231 MA152WA-X DIODE
D 332 MA152WK-X SI DIODE
D 351 MA152WK-X SI DIODE
D 451 MA152WK-X SI DIODE
D 701 CRS03-W SB DIODE
D 711 1SS355-X DIODE
D 754 UDZS6.2B-X SI DIODE
D 941 1SS355-X DIODE
D 961 1N5404-TU-15 DIODE
D 962 CRS03-W SB DIODE
D 963 MA152WA-X DIODE
D 967 CRS03-W SB DIODE
D 978 UDZ11B-X Z.DIODE
D 980 1SS355-X DIODE
D 986 MA152WA-X DIODE
IC 31 LA3460M-X IC
IC 51 SAA6579T-X IC
IC151 NJM4565M-W IC
IC171 NJM4565M-W IC
IC301 BA3220FV-X IC
IC321 M5282FP-XE IC
IC322 BU4066BCFV-X IC
IC323 NJM4565M-W IC
IC401 BA3220FV-X IC
IC501 TA2109F-X IC
IC521 TC9462F IC
IC581 FAN8037 IC
IC701 UPD784215GC-168 IC
IC702 IC-PST600M/G/-W IC
IC703 BR24C32F-X IC(EEPROM)
IC771 HD74HC126FP-X IC
IC821 NJM2100M-W IC
IC911 BD3860K IC (1008)
IC941 LA4743B IC
IC951 NJM2904M-W IC
IC961 BA4905-V3 IC
L 1 NQL334J-4R7X INDUCTOR
L 521 NQL114K-470X INDUCTOR
L 551 NQL114K-470X INDUCTOR
L 701 NQL114K-470X INDUCTOR
L 961 QQR0703-001 CHOKE COIL
PP 1 QZW0010-001 STYLE PIN
PP 3 QZW0010-001 STYLE PIN
PP 4 QZW0010-001 STYLE PIN
Q
1 UN2211-X TRANSISTOR
Q
11 2SB815/7/-X TRANSISTOR
Q
12 UN2211-X TRANSISTOR
Q
13 2SB709A/R/-X TRANSISTOR
Q
21 2SC2412K/R/-X TRANSISTOR
Q
22 2SC2412K/R/-X TRANSISTOR
Q
23 2SC2412K/R/-X TRANSISTOR
Q
24 UN2211-X TRANSISTOR
Q
31 UN2111-X TRANSISTOR
Q
32 UN2211-X TRANSISTOR
Q
33 2SD601A/R/-X TRANSISTOR
Q
34 UN2111-X TRANSISTOR
Q
35 2SB709A/R/-X TRANSISTOR
Q
36 UN2211-X TRANSISTOR
Q
131 2SD1048/6-7/-X TRANSISTOR
Q
132 2SD1048/6-7/-X TRANSISTOR
Q
161 2SD601A/R/-X TRANSISTOR
Q
231 2SD1048/6-7/-X TRANSISTOR
Q
232 2SD1048/6-7/-X TRANSISTOR
Q
321 UN2211-X TRANSISTOR
Q
322 UN2211-X TRANSISTOR
Q
323 2SD1048/6-7/-X TRANSISTOR
Q
501 2SB1241/QR/-T TRANSISTOR
Q
581 2SB1241/QR/-T TRANSISTOR
Q
701 DTC114EKA-X TRANSISTOR
Q
755 UN2211-X TRANSISTOR
Q
791 UN2211-X TRANSISTOR
Q
941 UN2211-X TRANSISTOR
Q
942 UN2211-X TRANSISTOR
Q
963 UN2213-X TRANSISTOR
Q
964 2SB709A/R/-X TRANSISTOR
Q
965 UN2211-X TRANSISTOR
Q
966 2SB709A/R/-X TRANSISTOR
Q
977 UN2111-X TRANSISTOR
Q
979 UN2111-X TRANSISTOR
Q
981 UN2111-X TRANSISTOR
Q
982 UN2211-X TRANSISTOR
Q
983 2SD601A/R/-X TRANSISTOR
Q
986 UN2211-X TRANSISTOR
R 1 NRSA02J-0R0X MG RESISTOR
R 2 NRSA02J-104X MG RESISTOR
R 3 NRSA02J-100X MG RESISTOR
R 4 NRSA02J-103X MG RESISTOR
R 11 NRS181J-8R2X MG RESISTOR
R 12 NRSA02J-473X MG RESISTOR
R 13 NRSA02J-472X MG RESISTOR
R 14 NRSA02J-473X MG RESISTOR
R 15 NRSA02J-332X MG RESISTOR
R 21 NRSA02J-473X MG RESISTOR
R 22 NRSA02J-393X MG RESISTOR
R 23 NRSA02J-103X MG RESISTOR
R 24 NRSA02J-222X MG RESISTOR
R 25 NRSA02J-103X MG RESISTOR
R 26 NRSA02J-153X MG RESISTOR
R 27 NRSA02J-471X MG RESISTOR
R 28 NRSA02J-683X MG RESISTOR
R 31 NRSA02J-123X MG RESISTOR
R 32 NRSA02J-474X MG RESISTOR
R 33 NRSA02J-222X MG RESISTOR
R 34 NRSA02J-392X MG RESISTOR
R 35 NRSA02J-333X MG RESISTOR
R 36 NRSA02J-683X MG RESISTOR
R 37 NRSA02J-222X MG RESISTOR
R 38 NRSA02J-183X MG RESISTOR
R 39 NRSA02J-223X MG RESISTOR
R 40 NRSA02J-562X MG RESISTOR
R 41 NRSA02J-105X MG RESISTOR
R 42 NRSA02J-471X MG RESISTOR
R 43 NRSA02J-104X MG RESISTOR
R 44 NRSA02J-102X MG RESISTOR
R 45 NRSA02J-473X MG RESISTOR
R 46 NRSA02J-683X MG RESISTOR
R 47 NRSA02J-0R0X MG RESISTOR
R 51 NRSA02J-101X MG RESISTOR
R 52 NRSA02J-222X MG RESISTOR
R 53 NRSA02J-222X MG RESISTOR
(Main board)
Item
Parts number Parts name Area
Remarks
A
