JVC KD-LX50R Service Manual

Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
C 601 NBE20JM-475X TS E CAPACITOR
C 602 NCB21HK-104X C CAPACITOR
C 603 NCB21HK-104X C CAPACITOR
C 604 NCB21HK-102X C CAPACITOR
C 605 NBE21AM-475X TS E CAPACITOR
C 606 NCB21HK-104X C CAPACITOR
C 607 NCB21HK-104X C CAPACITOR
C 608 NCB21HK-104X C CAPACITOR
C 609 NDC21HJ-101X C CAPACITOR
C 610 NBE20JM-475X TS E CAPACITOR
C 611 NBE21AM-106X E CAPACITOR
C 612 NFV41CG-393X MPPS CAPACITOR
C 613 NCZ1011-180X C CAPACITOR
C 614 NCB21EK-104X C CAPACITOR
C 615 NCB21HK-562X C CAPACITOR
C 625 NBE20JM-475X TS E CAPACITOR
CN601 QGF0501F1-16X FPC CONNECTOR
CN631 QGF0501F1-06X CONNECTOR C.M
D 621 SML-310LT/MN/-X LED
D 622 SML-310LT/MN/-X LED
D 623 SML-310LT/MN/-X LED
D 624 SML-310LT/MN/-X LED
D 625 MA3051/M/-X ZENER DIODE
D 626 MA152WK-X SI DIODE
D 627 LT1F67AF-W LED
D 655 CL-190UB-X-X LED
D 656 CL-190UB-X-X LED
IC601 LC75823W IC
IC602 LC75811W IC
IC603 RPM6938-SV4 IC
L 611 NQLZ007-680X INDUCTOR
L 612 NQR0372-001X C FL TRANSF
L 613 NQL114K-470X INDUCTOR
PC601 PR-20-W PHOTO REF.
PC602 PR-20-W PHOTO REF.
Q
611 2SD2185/R/-X TRANSISTOR
Q
612 2SD2185/R/-X TRANSISTOR
Q
691 2SD601A/R/-X TRANSISTOR
Q
692 2SD601A/R/-X TRANSISTOR
R 601 NRSA02J-103X MG RESISTOR
R 602 NRSA02J-103X MG RESISTOR
R 603 NRSA02J-103X MG RESISTOR
R 604 NRSA02J-473X MG RESISTOR
R 605 NRSA02J-103X MG RESISTOR
R 606 NRSA02J-103X MG RESISTOR
R 607 NRSA02J-103X MG RESISTOR
R 608 NRSA02J-103X MG RESISTOR
R 609 NRSA02J-153X MG RESISTOR
R 611 NRSA02J-472X MG RESISTOR
R 612 NRSA02J-472X MG RESISTOR
R 613 NRSA02J-681X MG RESISTOR
R 621 NRSA02J-221X MG RESISTOR
R 622 NRSA02J-221X MG RESISTOR
R 623 NRSA02J-821X MG RESISTOR
R 624 NRSA02J-821X MG RESISTOR
R 625 NRSA02J-471X MG RESISTOR
R 626 NRSA02J-103X MG RESISTOR
R 627 NRSA02J-221X MG RESISTOR
R 628 NRSA02J-0R0X MG RESISTOR
R 629 NRSA02J-102X MG RESISTOR
R 630 NRSA02J-102X MG RESISTOR
R 632 NRSA02J-221X MG RESISTOR
R 633 NRSA02J-221X MG RESISTOR
R 634 NRSA02J-221X MG RESISTOR
R 635 NRSA02J-221X MG RESISTOR
R 636 NRSA02J-821X MG RESISTOR
R 637 NRSA02J-821X MG RESISTOR
R 638 NRSA02J-122X MG RESISTOR
R 639 NRSA02J-182X MG RESISTOR
R 640 NRSA02J-272X MG RESISTOR
R 641 NRSA02J-392X MG RESISTOR
R 642 NRSA02J-821X MG RESISTOR
R 643 NRSA02J-821X MG RESISTOR
R 644 NRSA02J-122X MG RESISTOR
R 645 NRSA02J-182X MG RESISTOR
R 646 NRSA02J-272X MG RESISTOR
R 647 NRSA02J-392X MG RESISTOR
R 651 NRSA02J-221X MG RESISTOR
R 652 NRSA02J-221X MG RESISTOR
R 655 NRSA02J-391X MG RESISTOR
R 656 NRSA02J-391X MG RESISTOR
R 671 NRSA02J-331X MG RESISTOR
R 672 NRSA02J-331X MG RESISTOR
R 673 NRSA02J-332X MG RESISTOR
R 674 NRSA02J-332X MG RESISTOR
R 675 NRSA02J-332X MG RESISTOR
R 676 NRSA02J-391X MG RESISTOR
R 691 NRSA02J-104X MG RESISTOR
R 692 NRSA02J-393X MG RESISTOR
R 693 NRSA02J-104X MG RESISTOR
R 694 NRSA02J-393X MG RESISTOR
S 621 NSW0041-001X TACT SWITCH
S 622 NSW0041-001X TACT SWITCH
S 623 NSW0041-001X TACT SWITCH
S 624 NSW0041-001X TACT SWITCH
S 625 NSW0039-001X TACT SWITCH
S 631 QSW0856-002X TACT SWITCH
S 632 NSW0041-001X TACT SWITCH
S 633 QSW0856-002X TACT SWITCH
S 634 QSW0856-002X TACT SWITCH
S 635 QSW0856-002X TACT SWITCH
S 636 QSW0856-002X TACT SWITCH
S 637 QSW0856-002X TACT SWITCH
S 638 QSW0856-002X TACT SWITCH
S 639 QSW0856-002X TACT SWITCH
S 640 QSW0856-002X TACT SWITCH
S 641 QSW0856-002X TACT SWITCH
S 642 QSW0856-002X TACT SWITCH
S 643 QSW0856-002X TACT SWITCH
(LCD&Switch Board)
Item
Parts number Parts name Area
Remarks
A
