JVC KD-LX50R Service Manual

Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
C 841 QETM1CM-228 E CAPACITOR 2200MF 20% 16V
C 842 NCB21HK-103X C CAPACITOR
C 843 NCB21HK-102X C CAPACITOR
C 845 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 846 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 847 NCB21HK-104X C CAPACITOR
C 851 NDC21HJ-270X C CAPACITOR
C 852 NDC21HJ-270X C CAPACITOR
C 853 NDC21HJ-680X C CAPACITOR
C 854 NCB21HK-104X C CAPACITOR
C 855 NCB21HK-683X C CAPACITOR
C 856 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 857 NCB21HK-223X C CAPACITOR
C 858 NCS21HJ-221X C CAPACITOR
C 859 QEKJ1CM-107Z E CAPACITOR 100MF 20% 16V
C 860 NCB21HK-103X C CAPACITOR
C 861 QEKJ1CM-107Z E CAPACITOR 100MF 20% 16V
C 862 NCB21HK-104X C CAPACITOR
C 863 NCB21HK-103X C CAPACITOR
C 864 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 865 NCB21HK-104X C CAPACITOR
C 866 NCB21HK-104X C CAPACITOR
C 867 NCB21HK-104X C CAPACITOR
C 868 NDC21HJ-220X C CAPACITOR
C 869 NDC21HJ-220X C CAPACITOR
C 870 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 871 NCB21HK-473X C CAPACITOR
C 872 NCB21HK-103X C CAPACITOR
C 873 NCB21HK-103X C CAPACITOR
C 874 NCB21HK-103X C CAPACITOR
C 876 QETC0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 881 NCB21HK-223X C CAPACITOR
C 891 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 892 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 893 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 894 QEK41CM-106 E CAPACITOR 10MF 20% 16V
C 895 NCB21HK-103X C CAPACITOR
C 898 NCB21HK-562X C CAPACITOR
C 899 NCB21HK-102X C CAPACITOR
CN851 QGB2019K1-10S CONNECTOR
CN852 QGA2006C1-08 CONNECTOR
CN853 QGB2019J1-10S CONNECTOR
C1051 QEZ0509-47A EDL CAPACITOR PF
D 842 DSK10C-T1 DIODE
D 845 1SR154-400-X DIODE
D 851 DSK10C-T1 DIODE
D 865 1SS355-X DIODE
D 866 MA3051/M/-X ZENER DIODE
D 867 CRS03-W SB DIODE
D 891 1SS355-X DIODE
D1001 2A02 DIODE
D1051 CRS03-W SB DIODE
IC845 S-81250SGUP-X IC
IC851 RSC-300-TQFP VOICE IC
IC852 IC-PST600M/G/-W IC
IC853 SST28SF040120IE FLASH MEMORY
IC854 MSM534001E-77TS IC
IC855 UPD789104AMC504 IC
IC856 TC74VHCT08AF-X IC
IC857 TC74VHCT32AF-X IC
IC871 HD74HC126FP-X IC
IC891 NJM2100M-W IC
J 851 QNS0076-001 DCS JACK
J 852 QNS0076-002 CONNECTOR
J 853 QNZ0111-001 JACK
L 841 QQR0905-001 CHOKE COIL
L 851 NQL114K-470X INDUCTOR
Q
846 UN2211-X TRANSISTOR
Q
847 2SB1241/QR/-T TRANSISTOR
Q
851 2SB1241/QR/-T TRANSISTOR
Q
852 UN2211-X TRANSISTOR
Q
855 2SD601A/R/-X TRANSISTOR
Q
891 2SD1048X-6HL TRANSISTOR
Q
892 UN2111-X TRANSISTOR
R 192 NRSA02J-0R0X MG RESISTOR
R 292 NRSA02J-0R0X MG RESISTOR
R 841 NRSA02J-0R0X MG RESISTOR
R 845 NRSA02J-0R0X MG RESISTOR
R 847 NRSA02J-103X MG RESISTOR
R 848 NRSA02J-222X MG RESISTOR
R 850 QRL01DJ-470X OMF RESISTOR 47 5% 1/1W
R 851 NRSA02J-272X MG RESISTOR
R 852 NRSA02J-0R0X MG RESISTOR
R 853 NRSA02J-472X MG RESISTOR
R 854 NRSA02J-101X MG RESISTOR
R 855 NRSA02J-391X MG RESISTOR
R 856 NRSA02J-470X MG RESISTOR
R 858 NRSA02J-473X MG RESISTOR
R 859 NRSA02J-472X MG RESISTOR
R 860 NRSA02J-103X MG RESISTOR
R 862 NRSA02J-103X MG RESISTOR
R 863 NRSA02J-222X MG RESISTOR
R 864 NRSA02J-0R0X MG RESISTOR
R 865 NRSA02J-473X MG RESISTOR
R 866 NRSA02J-222X MG RESISTOR
R 867 NRSA02J-122X MG RESISTOR
R 868 NRSA02J-272X MG RESISTOR
R 871 NRSA02J-473X MG RESISTOR
R 872 NRSA02J-223X MG RESISTOR
R 873 NRSA02J-101X MG RESISTOR
R 874 NRSA02J-103X MG RESISTOR
R 875 NRSA02J-104X MG RESISTOR
R 876 NRSA02J-223X MG RESISTOR
R 877 NRSA02J-101X MG RESISTOR
R 878 NRSA02J-473X MG RESISTOR
R 879 NRSA02J-331X MG RESISTOR
R 880 NRSA02J-104X MG RESISTOR
R 881 NRSA02J-0R0X MG RESISTOR
R 884 NRSA02J-473X MG RESISTOR
R 885 NRSA02J-271X MG RESISTOR
R 886 NRSA02J-271X MG RESISTOR
R 887 NRSA02J-271X MG RESISTOR
R 888 NRSA02J-472X MG RESISTOR
R 889 NRSA02J-472X MG RESISTOR
R 890 NRSA02J-472X MG RESISTOR
R 891 NRSA02J-103X MG RESISTOR
R 892 NRSA02J-471X MG RESISTOR
R 893 NRSA02J-103X MG RESISTOR
R 894 NRSA02J-103X MG RESISTOR
R 895 NRSA02J-104X MG RESISTOR
R 896 NRSA02J-223X MG RESISTOR
R 897 NRSA02J-223X MG RESISTOR
R 898 NRSA02J-682X MG RESISTOR
R 899 NRSA02J-470X MG RESISTOR
RY851 QSK0079-001 RELAY
R1011 NRSA02J-473X MG RESISTOR
R1012 NRSA02J-473X MG RESISTOR
R1013 NRSA02J-473X MG RESISTOR
(Boice board)
Item
Parts number Parts name Area
Remarks
A
