30
ENGLISH
LVT1008-001A [E/EX]
Storing your own sound
adjustments
You can adjust the sound modes to your preference
and store your own adjustments in memory
(USER 1, USER 2 and USER 3).
• There is a time limit in doing the following
procedure. If the setting is canceled before you
finish, start from step
1
again.
1
Press BAND MODE (M).
“MODE” appears on the
display.
2
Press EQ (equalizer) while “MODE” is
still on the display.
The last selected sound mode is
called up.
3
Select the sound mode you want to
adjust.
4
Select sound elements to adjust.
Each time you press the
button, the sound elements
change as follows:
LOW FREQ.* = LOW WIDTH = LOW LEVEL =
MID FREQ.* = MID WIDTH = MID LEVEL =
HIGH FREQ.* = HIGH LEVEL =
(back to the beginning)
FREQ. (LOW, MID, HIGH):
Select the center frequency to adjust.
WIDTH (LOW, MID):
Select the band width level (Q).
LEVEL (LOW, MID, HIGH):
Adjust the enhancement level.
Ex.: If you have selected “JAZZ”
M
BAND
MODE
1
7
EQ
* By pressing ¢ or 4 , you
can directly move as follows:
5
Adjust the selected sound element.
• Refer to the table below
for adjusting the selected
sound element.
6
Repeat steps
4
and
5
to adjust the
other sound elements.
7
Select one of the user sound modes
(USER 1, USER 2, USER 3).
8
Press EQ to store the adjustments.
“MEMORY” appears for a while.
To reset to the factory settings
Repeat the same procedure and reassign the
preset values listed in the table on page 49.
Indication
WIDTH
LEVEL
FREQ.
Preset values
LOW MID HIGH
50 Hz 700 Hz 8 kHz
80 Hz 1 kHz 12 kHz
120 Hz 2 kHz
1 (min.) 1 (min.)
||
4 (max.) 2 (max.)
–06 (min.) –06 (min.) –06 (min.)
|| |
+06 (max.) +06 (max.) +06 (max.)
SEL
S
1
7
EQ
1
7
EQ
LOW FREQ. MID FREQ.
HIGH FREQ.
EN29-30KD-LX555R[E]f.p65 02.12.11, 16:3730
