22 ENGLISH
~
]
“EXT INPUT” or “AUX IN”
Ÿ Turn on the connected
component and start
playing the source.
!
]
Adjust the volume.
⁄ Adjust the sound as you
want. ( 23)
Connecting an external component to the AUX input jack
3.5 mm (3/16”) stereo mini plug
(not supplied)
Portable audio player,
etc.
Listening to the other external
components
You can connect an external component to:
• EXT INPUT: Expansion port on the rear of
this unit using the following adapters (not
supplied):
– KS-U57, Line Input Adapter
– KS-U58, AUX Input Adapter
Preparation: Make sure <EXT ON> is selected
for the <SRC SELECT>
=
<EXT IN> setting.
( 28)
• AUX IN: AUX (auxiliary) input jack on the
control panel.
Preparation: Make sure <AUX ON> is
selected for the <SRC SELECT>
=
<AUX IN>
setting. ( 28)
• For details, refer also to the instructions
supplied with the adapter or external
components.
