AUDIO SETTINGS
(For KD-R760 I KD-R660)
---------.----- ·------ ·--------------
. Lineout terminal
Setting . · · · FRONT I REAR I SW --- ---:-·
- REruvR - EAR ·--~-- F;;;;;; ~ ~~; -- - -----1· · - ~~~~ili~~~ ~ ~t ~-=~~ -
REAR!sus .w Front speakers output I Subwoofer output
~ tJB.W/SuiYJ - - Front speakers output I Subwoofer out~~ -;- ----·--·-
(For KD-AR565 I KD-R460)
-- -----,....-
T Lineout terminal
Settin~ . r------ ~- R - EA - R - I S -W ----------:--
REAR/REAR -~ Rear speakers output
REAR!SUB.W
Subwoofer output
SUB.WISUB .W
Subwoofer output
'
------~ - -- · -- · --·--·- - ·
• . Connection via speaker leads(~ 23)
Setting
l . Rear speaker lead
r- --------: -.-------- - .. ·---,--,.- · --- ---------- ·--
' l (left)
R (right)
REAR/REAR Rear speakers output . Rear speakers output
-~---·-·- ---·- · --- ------ - --
RE~R/SU8. W Rear speakers output Rear speakers output
SUB . WISUB.W Subwooferoutput (Mute)
If [SUB.WISUB . W] is sP.Iected :
-[HIGH
120HZ] is selected in [SUB.W LPF] and [THROUGH] is not available.
-
[R01] Is selected in [FADER] and selectable range is [R06] to [00]
•
DISPLAY SETTINGS·
KO-AR765S I KO-R760
AL L ZONE
KO-R660 I KO - R460
1<D-AR565
1 P.ress and hold DISP-SETUP.
2 Turn the vol .ume knob to make a selection {see the following table),
then press the knob. .
3 Repeat step 2 until
the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press
DISP-~.;TUP to exit .
To return to the preVious setting item, press 0./~.
DISPLAY
DIMMER
I
·I
i
l_
Default: XX
Selects the display a~d button illumination adjusted in the [BRIGHTNESS]
setting .
OFF: Selects the day adjustments :; ON: Selects the night adjustments . ;
DIMMER TIME : AdjustS the dimmer on and off time.
Turn the volume knob to adjust the [ ON] time, then press the knob.
Turn the volume knob to adjust the [OFF] time, then press the knob .
(
Default: [ON] :· 18:00 or 6: 00PM ·
[OFF]: 6: 00 or 6:00AM)
AUTO: Change~between the day and night adjustments when you turn off or
on the car headlights. *1
For KD-AR765S 'I KD-R760 I KD-AR565 , the di s play and button colors
change according to the settings made on [COLOR].
*1 The illumination control wire connection is required. <• 23)
