JVC KD-R794BT User Manual

ENGLISH
13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pair and connect a Bluetooth device for the first time
1
Press source button to turn on the unit.
2 Search and select “KD-R9 BT”/“KD-R8 BT”/“KD-R7 BT” on the Bluetooth device.
“BTPAIRING” flashes on the display.
• For some Bluetooth devices, you may need to enter the Personal Identification Number
(PIN) code immediately after searching.
3 Perform (A) or (B) depending on what appears on the display.
For some Bluetooth devices, pairing sequence may vary from the steps described below.
(A)
KD-R992BT / KD-R899BT / KD-R794BT / KD-R792BT :
“[Device Name]”
“XXXXXX” “VOL–YES” “BACK–NO”
KD-R891BT :
“[Device Name]”
“XXXXXX” “ENTER–YES” “BACK–NO”
“XXXXXX” is a 6-digit passkey randomly generated during each pairing.
Ensure that the passkeys appear on the unit and Bluetooth device are the same.
Press the following operation to confirm the passkey.
KD-R992BT / KD-R899BT / KD-R794BT / KD-R792BT : volume knob
KD-R891BT :
Operate the Bluetooth device to confirm the passkey.
(B) KD-R992BT / KD-R899BT / KD-R794BT / KD-R792BT :
“[Device Name]”
“VOL–YES” “BACK–NO”
KD-R891BT :
“[Device Name]”
“ENTER–YES” “BACK–NO”
Press the following to start pairing.
KD-R992BT / KD-R899BT / KD-R794BT / KD-R792BT : volume knob
KD-R891BT :
• If “PAIRING” “PIN 0000” scrolls on the display, enter the PIN code “0000” into the
Bluetooth device.
You can change to a desired PIN code before pairing.
( 17)
• If only “PAIRING” appears, operate the Bluetooth device to confirm pairing.
“PAIRING COMPLETED” appears when pairing is completed and “ ” will light up when the
Bluetooth connection is established.
• This unit supports Secure Simple Pairing (SSP).
• Up to five devices can be registered (paired) in total.
• Once the pairing is completed, the Bluetooth device will remain registered in the unit even if
you reset the unit. To delete the paired device,
17 , [DEVICE DELETE] .
BLUETOOTH®
• A maximum of two Bluetooth phones and one
Bluetooth audio device can be connected at any
time.
However, while in BT AUDIO source, you can
connect to five Bluetooth audio devices and
switch between these five devices. (
19 )
• Some Bluetooth devices may not automatically
connect to the unit after pairing. Connect the
device to the unit manually.
• Refer to the instruction manual of the Bluetooth
device for more information.
Auto Pairing
When you connect the following devices to the USB
input terminal, pairing request (via Bluetooth) is
automatically activated.
KD-R992BT / KD-R899BT / KD-R891BT : iPhone/iPod touch/
Android device
KD-R794BT / KD-R792BT : Android device
Press the following to pair once you have
confirmed the device name.
KD-R992BT / KD-R899BT /
KD-R794BT / KD-R792BT : volume knob
KD-R891BT :
Automatic pairing request is activated only if:
– Bluetooth function of the connected devcie is
turned on.
–
[AUTO PAIRING] is set to [ON] . ( 18)
– JVC MUSIC PLAY application is installed on
the Android device
( 8) and [AUTO MODE] is
selected
( 9) .
JS_JVC_KD_R992BT_E_EN_3.indd 13JS_JVC_KD_R992BT_E_EN_3.indd 13 7/27/2017 9:46:51 AM7/27/2017 9:46:51 AM

JVC KD-R794BT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
DIN size	1 DIN
Output power	200 W
Product color	Black
Ready for iPod	No
Disc types supported	CD, CD-R, CD-RW
Audio output channels	- channels
Equalizer bands quantity	11
Maximum power per channel	50 W
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	24
Display type	LCD
Display number of lines	2 lines
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Key illumination color	Red

Weight and Dimensions

Weight	1200 g
Dimensions (WxDxH)	182 x 158 x 53 mm
