TROUBLESHOOTING
Symptom Remedy
Bluetooth®
The connected Bluetooth
audio player cannot be
controlled.
• Check whether the connected Bluetooth audio player
supports Audio/Video Remote Control Profile (AVRCP).
(Refer to the instructions of your audio player.)
• Disconnect and connect the Bluetooth player again.
“PLEASE WAIT”
The unit is preparing to use the Bluetooth function. If
the message does not disappear, turn off and turn on
the unit, then connect the device again.
“NOT SUPPORT”
The connected phone does not support Voice
Recognition feature.
“ERROR”
Try the operation again. If “ERROR” appears again, check
if the device supports the function you have tried.
“H/W ERROR”
Reset the unit and try the operation again. If “H/W
ERROR” appears again, consult your nearest service
center.
“SWITCHING NG”
The connected phones might not support phone
switching feature.
If you still have troubles, reset the unit. ( 3 or 4)
INSTALLATION/CONNECTION
Warning
• The unit can only be used with a 12V DC power supply, negative ground.
• Disconnect the battery’s negative terminal before wiring and mounting.
• Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire
(black) to prevent a short circuit.
• To prevent short circuit:
– Insulate unconnected wires with vinyl tape.
– Be sure to ground this unit to the car’s chassis again after installation.
– Secure the wires with cable clamps and wrap vinyl tape around the wires that comes into
contact with metal parts to protect the wires.
Caution
• For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer.
• Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during and
shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.
• Do not connect the
wires of speakers to the car chassis or Ground wire (black), or connect
them in parallel.
• Connect speakers with a maximum power of more than 50W. If the maximum power of the
speakers is lower than 50W, change the [AMP GAIN] setting to avoid damaging the speakers.
(
22)
• Mount the unit at an angle of less than 30º.
• If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red) to
the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned on and
off by the ignition key.
• Keep all cables away from heat dissipate metal parts.
• After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are
working properly.
• If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old fuse
with one that has the same rating.
Basic procedure
1 Remove the key from the ignition switch, then disconnect the terminal of the car
battery.
2 Connect the wires properly.
See Wiring connection. (
35)
3 Install the unit to your car.
See Installing the unit (in-dash mounting). (
34)
4 Connect the
terminal of the car battery.
5 Press source button to turn on the power.
6 Detach the faceplate and reset the unit within 5 seconds. ( 3 or 4)
JS_JVC_KD_R992BT_E_EN_3.indd 33JS_JVC_KD_R992BT_E_EN_3.indd 33 7/27/2017 9:47:21 AM7/27/2017 9:47:21 AM

JVC KD-R794BT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
DIN size	1 DIN
Output power	200 W
Product color	Black
Ready for iPod	No
Disc types supported	CD, CD-R, CD-RW
Audio output channels	- channels
Equalizer bands quantity	11
Maximum power per channel	50 W
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	24
Display type	LCD
Display number of lines	2 lines
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Key illumination color	Red

Weight and Dimensions

Weight	1200 g
Dimensions (WxDxH)	182 x 158 x 53 mm
