AJUSTES DE AUDIO
Elementos de ajuste de crossover de 2 vías
SPEAKER SIZE
FRONT SIZE
8CM/10CM/12CM/13CM/16CM/17CM/18CM
/
4×6
/
5×7
/
6×8
/
6×9
/
7×10
TWEETER
SMALL
/
MIDDLE
/
LARGE
/
NONE
(no conectado)
REAR
*
1
8CM/10CM/12CM/13CM/16CM/17CM/18CM
/
4×6
/
5×7
/
6×8
/
6×9
/
7×10
/
NONE
(no conectado)
SUBWOOFER
*
2
*
3
16CM/20CM/25CM/30CM/38CM OVER
/
NONE
(no conectado)
X ' OVER
TWEETER FRQ
1KHZ
/
1.6KHZ
/
2.5KHZ
/
4KHZ
/
5KHZ
/
6.3KHZ
/
8KHZ
/
10KHZ
/
12.5KHZ
GAIN LEFT
–08DB
a
00DB
GAIN RIGHT
–08DB
a
00DB
FRONT HPF F-HPF FRQ
30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
F-HPF SLOPE
–06DB
/
–12DB
/
–18DB
/
–24DB
F-HPF GAIN
–08DB
a
00DB
REAR HPF
*
1
R-HPF FRQ 30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
R-HPF SLOPE
–06DB
/
–12DB
/
–18DB
/
–24DB
R-HPF GAIN
–08DB
a
00DB
SUBWOOFER
LPF
*
2
*
3
SW LPF FRQ 30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
SW LPF SLOPE
–06DB
/
–12DB
/
–18DB
/
–24DB
SW LPF PHASE
REVERSE
(180°)/
NORMAL
(0°)
SW LPF GAIN –08DB
a
00DB
Elementos de ajuste de crossover de 3 vías
SPEAKER SIZE
TWEETER
SMALL/MIDDLE/LARGE
MID RANGE
8CM/10CM/12CM/13CM/16CM/17CM/18CM
/
4×6
/
5×7
/
6×8
/
6×9
WOOFER
*
3
16CM/20CM/25CM/30CM/38CM OVER
/
NONE
(no conectado)
X ' OVER
TWEETER HPF FRQ
1KHZ
/
1.6KHZ
/
2.5KHZ
/
4KHZ
/
5KHZ
/
6.3KHZ
/
8KHZ
/
10KHZ
/
12.5KHZ
SLOPE
–06DB
/
–12DB
PHASE
REVERSE
(180°)/
NORMAL
(0°)
GAIN –08DB
a
00DB
MID RANGE HPF FRQ
30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
HPF SLOPE
–06DB
/
–12DB
LPF FRQ
1KHZ
/
1.6KHZ
/
2.5KHZ
/
4KHZ
/
5KHZ
/
6.3KHZ
/
8KHZ
/
10KHZ
/
12.5KHZ
/
THROUGH
LPF SLOPE
–06DB
/
–12DB
PHASE
REVERSE
(180°)/
NORMAL
(0°)
GAIN –08DB
a
00DB
WOOFER
*
3
LPF FRQ 30HZ
/
40HZ
/
50HZ
/
60HZ
/
70HZ
/
80HZ
/
90HZ
/
100HZ
/
120HZ
/
150HZ
/
180HZ
/
220HZ
/
250HZ
/
THROUGH
SLOPE
–06DB
/
–12DB
PHASE
REVERSE
(180°)/
NORMAL
(0°)
GAIN –08DB
a
00DB
*
1
Se visualiza sólo cuando
[SPK/PRE OUT]
se ajusta a
[REAR/REAR]
o
[REAR/SUB.W]
.
( 22, 23)
*
2
Se visualiza sólo cuando
[SPK/PREOUT]
se ajusta a
[REAR/SUB.W]
o
[SUB.W/SUB.W]
.
( 22, 23)
*
3
Se visualiza sólo cuando
[SUBWOOFER SET]
se ajusta a
[ON]
.
( 21)
