ENGLISH
24
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output.
( 35)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFER LPF] and [THROUGH] is not available.
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION
R15]
to [POSITION 00] .
Speaker output settings [SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY]) (
23)
Select the output setting for the speakers [SPK/PRE OUT] , based on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. ( 35)
KD-R988BTS
:
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
REAR/REAR
(default)
Front speakers output Rear speakers output Subwoofer output
REAR/SUB.W ( Not available ) ( Not available ) ( Not available )
SUB.W/SUB.W Front speakers output L (left): Subwoofer
output
R (right): (Mute)
Subwoofer output
KD-R888BT :
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
REAR/REAR Front speakers output Rear speakers output
REAR/SUB.W (default) Front speakers output Subwoofer output
SUB.W/SUB.W Front speakers output Subwoofer output
